Kinze 3200 Wing-Fold Planter Rev. 5/14 - Manual (Page 131)

Liquid Fertilizer Piston Pump Drive
ITEM PART NO. QTY. DESCRIPTION
11 GD5857 1 Spring
12 G10306
G11387
G10108 1
2
1
Carriage Bolt, ⅜"-16 x 2"
Flat Washer, ⅜" SAE
Lock Nut, ⅜"-16
13 GD5860 1 Bar
14 G10023
G10227
G10103 2
2
2
Hex Head Cap Screw, ¼"-20 x ¾"
Lock Washer, ¼"
Hex Nut, ¼"-20
15 G10303
G10232
G10106 6
6
6
Carriage Bolt, 5∕16"-18 x 1"
Lock Washer, 5∕16"
Hex Nut, 5∕16"-18
16 G3400-01 4 Flangette
17 G2100-03 2 Bearing, ⅞" Hex Bore, Spherical
18 GD6825-12.25 1 Hex Shaft, ⅞" x 12¼" (2 Holes)
19 GA5118 1 Mount
20 G10001
G10370
G10229
GD5756 1
1
1
1
Hex Head Cap Screw, ⅜"-16 x 1"
Machine Bushing, ⅜", 22 Gauge
Lock Washer, ⅜"
Special Nut, ⅜"-16
21 G10751
G10235
G11391
G10412 2
6
2
2
Hex Head Cap Screw, ⅝"-18 x 1¾"
Machine Bushing, ⅞", 14 Gauge
Flat Washer, ⅝" SAE
Lock Nut, ⅝"-18
22 A7370
G10303
G10232
G10106
GA9846
G10055
G10107 1
6
6
6
-
2
2
Arm W/Flanged Bearings And Hardware (Non-Stock Item) (Sub G1K253)
Carriage Bolt, 5∕16"-18 x 1"
Lock Washer, 5∕16"
Hex Nut, 5∕16"-18
Flanged Bearing, ⅞" Hex Bore
Hex Head Cap Screw, ⅝"-11 x 1¼" (Stop Bolt)
Lock Nut, ⅝"-11
23 GB0218 2 Bushing, 21∕32" I.D. x ⅞" O.D. x 19∕32" Long
24 GA2068 1 Spring W/Plug
25 G10501 2 Hex Jam Nut, ½"-13, Grade 2
26 G10003
G11387
GR1122
G10229
G10101 4
4
4
4
4
Hex Head Cap Screw, ⅜"-16 x 1½"
Flat Washer, ⅜" SAE
Mounting Pad
Lock Washer, ⅜"
Hex Nut, ⅜"-16
27 G10207 2 Washer, ⅞" O.D. x 13∕32" I.D. x .134"
28 GB0258 1 Stepped Spacer, ⅞"
29 GD2558 1 Lynch Pin, ¼"
30 GA8168 1 Pump Mount
31 GD7145
G10228
G10102 1
2
2
U-Bolt, 7" x 7" x ½"-13
Lock Washer, ½"
Hex Nut, ½"-13
32 G3310-66
GR0912 1
-
Chain, No. 40, 66 Pitch Including Connector Link
Connector Link, No. 40
