ITEM
PART NO.
QTY.
(Per Assy.)
DESCRIPTION
33
G10496
2
External Inverted Snap Ring, 1½"
34
G11075
3
External Inverted Snap Ring, ⅞"
35
GD14432
1
Sleeve, 1¼"
36
GD14431
1
Handle
37
GD14427
1
Tightener Shaft, 4⅞"
38
GD19343
GD19344
1
-
Release Collar, R.H. (Shown)
Release Collar L.H.
39
GD14413
GD14414
-
1
Torsion Spring, L.H. (Shown)
Torsion Spring, R.H.
40
G11100
G10227
G11453
1
1
1
Hex Socket Button Head Cap Screw, ¼"-20 x ½", Grade 8
Lock Washer, ¼"
Fender Washer, ¼"
41
G11078
1
Vinyl Cap
A
G1K269
-
Lock Clamp Kit (Items 28 And 28)
B
G1K378
G1K379
1
-
Wrap Spring Wrench Replacement Kit, Blue Collar, R.H. (Items 33-41) (Shown)
Wrap Spring Wrench Replacement Kit, Gray Collar, L.H. (Items 33-41)
Seed Rate Transmission Assembly and Driveline
M0241-02
Model 3200
P81
Rev. 1/12
