Decals, Paint, and Miscellaneous
M0241-02
Model 3200
P149
Rev. 7/12
TM
Part No.: G7100-234
Description: Decal, Bolt Torque
Quantity: -
Part No.: G7100-121
Description: Decal, Transmission, R.H.
Quantity: 1
Part No.: G7100-124
Description: Decal, Transmission, L.H.
Quantity: 1
Part No.: G7100-192
Description: Decal, Point Row Coutch Rotation
Part No.: G7100-153
Description: Decal, Information
Quantity: 1 Per Brush-Type Seed Meter
MARKER
FOLD
7100-337
RELEASE
HYDRAULIC
PRESSURE
BEFORE TURNING
VALVE
Part No.: G7100-337
Description: Decal, Instruction
EdgeVac
®
PROTECTED BY THE FOLLOWING PATENTS
UNITED STATES
7,093,548 7,152,542
7100-456
Part No.: G7100-456 (replaces G7100-311)
Description: Decal, EdgeVac
NOTICE
-FAN MOTOR CASE DRAIN-
ALWAYS CONNECT THE FAN MOTOR
CASE DRAIN HOSE TO THE TRACTOR
ZERO PRESSURE RETURN. DO NOT
CONNECT TO THE TRACTOR SCV OR
MOTOR RETURN PORTS AS FAN
HYDRAULIC MOTOR FAILURE WILL
OCCUR.
7100-329
Part No.: G7100-329
Description: Tag, Fan Motor Case Drain
