Frame/manifold assembly – Kinze 3200 Wing-Fold Planter Rev. 5/14 User Manual
Page 59
ITEM
PART NO.
QTY.
DESCRIPTION
1
---
-
See “Miscellaneous” on page P141
2
GD2200
1
Spade
3
GA7513
1
Spring Canister W/Mounting Hardware (Includes Item 3 And 6)
4
GA6055
2
Arm
5
G10023
G10110
2
2
Hex Head Cap Screw, ¼"-20 x ¾"
Lock Nut, ¼"-20, Grade B
6
GD3311
G10457
2
4
Pin, ⅞" x 3⅛"
Cotter Pin, 5∕32" x 1½"
7
G10640
4
Grease Fitting, ¼"-28
8
G10404
4
Machine Bushing, 3⅛" x 2⅛" x 3∕16"
9
GA8033
2
Pin
10
G10007
G10230
G10104
2
2
2
Hex Head Cap Screw, ⅝"-11 x 1½"
Lock Washer, ⅝"
Hex Nut, ⅝"-11
11
GD3373
G11396
G10236
GD9688
2
4
2
2
Eyebolt
Flat Washer, 1¼"
Lock Washer, 1¼"
Special Nut, 1¼"-7
12
GD11298
G10457
2
4
Pin, ⅞" x 69∕16"
Cotter Pin, 5∕32" x 1½"
13
GA8335
1
Hook
14
GD7972
1
Turnbuckle
15
GD3373
1
Eyebolt
16
GA7022
1
Detent Pin W/Chain
17
GD11300
1
Lockup
18
G10017
G10228
G10102
1
1
1
Hex Head Cap Screw, ½"-13 x 1½"
Lock Washer, ½"
Hex Nut, ½"-13
19
G10235
-
Machine Bushing, ⅞", 14 Gauge
20
A11939
A8116
A11938
A8036
-
-
-
-
Frame, 8 Row 36"/38", 302", (Includes Items 7-10)
(Non-Stock Item) (EdgeVac)
Frame, 8 Row 36"/38", 302", (Includes Items 7-10)
(Non-Stock Item) (Mechanical)
Frame, 12 Row 30", 351½", (Includes Items 7-10)
(Non-Stock Item) (EdgeVac)
Frame, 12 Row 30", 351½", (Includes Items 7-10)
(Non-Stock Item) (Mechanical)
21
GD3311
G10457
2
4
Pin, ⅞" x 3⅛"
Cotter Pin, 5∕32" x 1½"
22
G10108
2
Lock Nut, ⅜"-16
23
GD14534
-
Hose Clamp, ¾" x 4" x 4½"
24
GD7948
G10461
1
2
Shaft, 2⅛" x 20"
Cotter Pin, ⅜" x 3"
25
GD17046
1
Mount
26
G10581
G10111
1
1
Hex Head Cap Screw, ½"-13 x 2¼"
Lock Nut, ½"-13
27
G10599
G10622
2
2
Carriage Bolt, ⅜"-16 x 1¼"
Serrated Flange Nut, ⅜"-16
28
GD17061-01
2
Foam Seal (EdgeVac Only)
29
GA11968
4
Flapper (EdgeVac Only)
30
GD17106
4
Tube, 6" x 6" x ½" (EdgeVac Only)
31
GD17105-01
4
Round Shaft, ¼" x 6" (EdgeVac Only)
32
G11214
G10103
16
16
Hex Socket Set Screw, ¼"-20 x ¾" (EdgeVac Only)
Hex Nut, ¼"-20 (EdgeVac Only)
33
---
-
(EdgeVac Only)
See “Vacuum Fan Mounting Brackets and Distribution Hoses” on
Frame/Manifold Assembly
TM
Model 3200
M0241-02
6/11
P56
