ITEM
PART NO.
QTY.
DESCRIPTION
1
GR1415
1
Rotation Sensor
2
GD11169
1
Mount
3
G10757
G10243
G10758
2
2
2
Pan Head Screw, No. 10-32 x 1¼"
Washer, No. 10 SAE
Hex Nut, No. 10-32
4
GD11474
2
Cover
5
GD5857
2
Spring
6
GD11170
1
Spring Mount
7
GR1414
1
Actuator
8
G10927
G10931
G10928
2
2
2
Pan Head Machine Screw, No. 8-32 x 1¼", Stainless Steel
Lock Washer, No. 8, Internal/External, Stainless Steel
Hex Nut, No. 8-32, Stainless Steel
9
G1K364
-
Rotation Sensor Mount Kit, Includes: (2) Mounts, (2) GD11721 5" x 7" U-Bolts,
(4) G10228 Lock Washers, (4) G10102 Hex Nuts, (1) Instruction
10
GA8026
-
Radar Sensor Pipe/Mounting Bracket Package
11
G1K323
-
4-Pin Connector Kit W/Female Housing, (4) Pins And (1) Cable Clamp
12
GA7858
-
Radar Distance Sensor W/20' Cable
13
GA5600
1
Magnetic Distance Sensor
14
GD8751
-
Magnetic Distance Sensor Pulse Wheel
15
GD6291
-
Insulated Clamp, ⅜"
16
GD8770
1
Bracket
17
G10001
G10229
G10101
2
2
2
Hex Head Cap Screw, ⅜"-16 x 1"
Lock Washer, ⅜"
Hex Nut, ⅜"-16
18
GA7856
1
Power Lead Adapter
19
G1K267
-
Power Lead Adapter Connector Kit, Includes: (1) 3-Pin Connector, (1) Cable Clamp,
(3) Male Terminal Pins
20
G1K268
-
Console Cable Connector Kit, Includes: (1) 3-Pin Connector, (1) Cable Clamp, (1)
Lock Ring, (3) Female Terminal Pins
21
GA9857
GR1631
GR1632
1
-
-
SMM Backlit Console W/Mounting Bracket And Dust Plug (Item 36)
Mounting Bracket, KPM II Stack-Mode And SMM Consoles
Console Mounting Bracket Hardware Package (Includes 2 Knobs And ¼" Hardware)
22
GA9144
-
Monitor/Radar Adapter Cable, 10"
23
G1K322
-
4-Pin Connector Kit W/Male Housing, (4) Female Socket Contacts And (1) Cable
Clamp
24
G10022
G11385
G10227
G10103
2
2
2
2
Hex Head Cap Screw, ¼"-20 x ½"
Flat Washer, ¼" SAE
Lock Washer, ¼"
Hex Nut, ¼"-20
25
GA10575
GR1391
GR1393
GA10601
GD7639
-
-
-
-
-
KPM II Backlit Console W/Mounting Bracket, Fuse Holder And Fuse, Power Lead
Adapter (Item 18), Brush (Item 28), Dust Plug (Item 36) And Monitor/Radar Adapter,
10" (Item 22)
Mounting Bracket, KPM II
Console Mounting Bracket Hardware Package (Includes 4 Knobs And ¼" Hardware)
Fuse Holder
Fuse
26
---
-
Included In Light Wiring Harness. See Item 10 On
27
GA7850
GA7851
GD11993
1
-
-
Planter Harness W/Dust Caps, 8 Row (12 Connectors)
Planter Harness W/Dust Caps, 12 Row (16 Connectors)
Dust Cap
28
GR0594
-
Brush
KPM II Stack-Mode Electronic Seed Monitor
TM
Model 3200
M0241-02
6/11
P100
