Kinze 3200 Wing-Fold Planter Rev. 5/14 - Manual (Page 61)

ITEM PART NO. QTY. DESCRIPTION
1 GD9762
G10463 4
8 Pin, 1" x 3½"
Cotter Pin, ¼" x 1½"
2 GD5900-12 4 Sleeve, ⅜"
3 GD9591
G10463 2
8 Pin, 1" x 5¾"
Cotter Pin, ¼" x 1½"
4 GD11177
G10463 2
8 Pin, 1" x 7¼"
Cotter Pin, ¼" x 1½"
5 GD9589 2 Link
6 GA6800 2 Link
7 G6801-06-08
GR1037 4
-
Elbow W/O-Ring, 90°, 9∕16"-18 Male JIC To ¾"-16 O-Ring
O-Ring
8 *A1168 2 Hose Assembly, ¼" x 120"
9 --- - See “Hydraulic Wing Fold Cylinder” on page P90
10 *A1106 2 Hose Assembly, ¼" x 130"
11 G10580
G10227
G10103 2
2
2 Hex Head Cap Screw, ¼"-20 x 3"
Lock Washer, ¼"
Hex Nut, ¼"-20
12 GD9699 1 Mounting Angle
13 G10064
G10227
G10103 2
2
2 Hex Head Cap Screw, ¼"-20 x 1"
Lock Washer, ¼"
Hex Nut, ¼"-20
14 --- - See “Hydraulic System” on page P93
15 *A3180 2 Hose Assembly, ⅜" x 25"
16 G6400-06
GR1045 4
-
Connector W/O-Ring, 9∕16"-18 Male JIC To O-Ring
O-Ring
17 --- - See “Hydraulic Wing Fold Selector Valve” on page P92
18 G6400-08-06
GR1045 4
-
Connector W/O-Ring, ¾"-16 Male JIC To 9∕16"-18 O-Ring
O-Ring
19 G2406-08-06 2 Reducer, ¾"-16 Female JIC To 9∕16"-18 Male JIC
* Hydraulic hose is not stocked by Kinze Repair Parts, but can be made available on a special order basis. Call for quote.
Hydraulic Wing Fold
TM
Model 3200 M0241-02
