Kinze 3200 Wing-Fold Planter Rev. 5/14 - Manual (Page 63)

ITEM PART NO. QTY.
(Per Assy.)
DESCRIPTION
1 GA9877
G10640 1
-
Clamp W/Grease Fittings
Grease Fitting, ¼"-28
2 G10006
G10230
G10104
G11391 2
2
2
2 Hex Head Cap Screw, ⅝"-11 x 2¼"
Lock Washer, ⅝"
Hex Nut, ⅝"-11
Flat Washer, ⅝", SAE
3 GA5122 1 Wheel Tower Clamp
4 GA7944 1 Lockup Mount
5 G10004
G11091 2
2 Hex Head Cap Screw, ⅜"-16 x 1¼"
Serrated Flange Nut, ⅜"-16
6 G10053
G10111 2
2 Hex Head Cap Screw, ½"-13 x 2½"
Lock Nut, ½"-13
7 GA5121 2 Pin, 2⅛"
8 GD11695
G10610 1
2 Pin, 1¼" x 13¼"
Spring Pin, ⅜" x 2"
9 GA8839 1 Arm
10 G10006
G11391
G10230
G10104 4
4
4
4 Hex Head Cap Screw, ⅝"-11 x 2¼"
Flat Washer, ⅝", SAE
Lock Washer, ⅝"
Hex Nut, ⅝"-11
11 GD5841
G10460 1
2 Pin, 1¼" x 5⅝"
Cotter Pin, ¼" x 2"
12 --- - See “Contact Wheel and Arm Assembly” on page P65
13 --- - See “Master Lift Cylinder” on page P87
See “Slave Lift Cylinder” on page P87
See “Assist Cylinder” on page P88
14 GA9870 1 Lockup W/Pin
15 G10026
G10231 2
2 Hex Head Cap Screw, ¾"-10 x 2"
Lock Washer, ¾"
16 GD12543 1 Scraper
17 G11396 2 Flat Washer, 1¼" SAE
18 G10636
G10071 4
4 Carriage Bolt, ½"-13 x 1½"
Serrated Flange Nut, ½"-13
19 G10025
G10231
G10105 2
2
2 Hex Head Cap Screw, ¾"-10 x 1½"
Lock Washer, ¾"
Hex Nut, ¾"-10
20 GA7376 1 Scraper Mount
21 GA14413 1 Rim, 5.50" x 20"
22 GA7434 1 Valve Stem
23 GD13401 - Tire, 7.50" x 20", 8 Ply Tubeless W/O Center Rib (Specify Brand*)
24 GA2558
GD11490 1
-
Spindle W/Round External Retaining Ring, 9½"
Round External Retaining Ring
25 GA0895 2 Bearing
26 GR0270 6 Lug Bolt, 9∕16"-18
27 GA2148
GR0434 1
-
Hub W/Cups, 6 Bolt
Cup
28 G11081 2 Hex Jam Nut, 1½"-12, Grade 2
29 G10159 2 Machine Bushing, 1¼", 10 Gauge (As Required)
A GA4377 - Hub And Spindle Assembly (Items 24, 25, And 27-28)
B GA7409 - Scraper Assembly (Items 16 And 18-20)
C GA14412 - Tire and Rim Assembly (Items 21-23)
*Specific brand requests will be supplied only as available from current Kinze Repair Parts stock. If a specific
brand requested is not in stock, the brand available will be supplied.
Transport and Ground Drive Wheel Assembly
(Prior to 2012 Production)
TM
Model 3200 M0241-02
Rev. 1/12 P60
