Decals, Paint, and Miscellaneous

M0241-02

Model 3200

P147

Rev. 7/12

Part No.: G7100-71 (used prior to 2013 production)

(replaced by G7100-402)

Description: Decal, Warning

Quantity: 2 (One Located On Upper Side Of Each Inner

Wheel Module Arm Clamp On Each Side Of
Planter)

Part No.: G7100-66 (used prior to 2013 production)

(replaced by G7100-402)

Description: Decal, Warning

Quantity: 2 (One Located On Upper Side Of Each Outer

Wheel Module Arm Clamp On Center Frame On
Each Side Of Planter)

Uncontrolled movement of

planter components can cause

death, serious injury, or damage

to property and equipment.

Raise planter and install cylinder

lockups before folding. Fold on

level ground. Install wing safety

latches before towing.

7100-402

WARNING

Part No.: G7100-402 (2013 production and on) (replaces

G7100-71 and G7100-66)

Description: Decal, Warning

Quantity: 2 (One Located On Upper Side Of Each Inner

Wheel Module Arm Clamp On Each Side Of
Planter)

Part No.: GD1162

Description: Tie Strap, 28"

Part No.: GD1512

Description: Tie Strap, 7½"

Part No.: GD2117

Description: Tie Strap, 14½"

Part No.: GD2984

Description: Tie Strap, 34"
