ITEM PART NO. QTY. DESCRIPTION
1 GD14626 24 Elbow, 90°, 2"
2 G10676 - Hose Clamp. No. 36, Stainless Steel
3 GD15792-19
GD15792-20 10
2
Hose, 2" x 34"
Hose, 2" x 32"
4 GD15867-03 2 Hose, 5" x 36"
5 G11188 4 T-Bolt Clamp, 5¼"
6 GA11940 2 Manifold Elbow
7 G11166 10 Whix Lock Bolt, ¼"-20 x ¾"
8 G10023
G10110 8
8 Hex Head Cap Screw, ¼"-20 x ¾"
Lock Nut, ¼"-20, Grade B
9 GD16842 2 Manifold Gasket, ⅛" x 8⅜" (6⅝" I.D.)
10 GA11945 1 Fan Drop Housing
11 GD16840 1 Cover
12 GD16991 1 Cover Gasket, ⅛" x 8⅜" (6½" I.D.)
13 G11204 4 Hex Head Cap Screw, ⅜"-16 x 1¼"
14 GD16992 2 Gasket, ⅛" x 11⅞"
15 GD16839 1 Spacer, ½" x 12"
16 --- - See “Digital Vacuum Gauge, Analog Vacuum Gauge, and Vacuum Fan Assembly” on
page P46
17 G10017
G10228
G10102 3-4
3-4
3-4 Hex Head Cap Screw, ½"-13 x 1½"
Lock Washer, ½"
Hex Nut, ½"-13
18 GA11946 1 Support
19 G10016
G10228
G10102 1
1
1 Hex Head Cap Screw, ½"-13 x 2"
Lock Washer, ½"
Hex Nut, ½"-13
20 GD17074 1 Brace
21 G10005
G11391
G10230
G10104 1
1
1
1 Hex Head Cap Screw, ⅝"-11 x 1¾"
Flat Washer, ⅝" SAE
Lock Washer, ⅝"
Hex Nut, ⅝"-11
22 GD17073 1 Spacer, 4½" x 4½"
23 --- - See “Vacuum Fan Motor Valve Block Assembly (Located Below Vacuum Fan Motor
Assembly)” on page P49
24 G10326
G10229
G10101 2
2
2 Hex Head Cap Screw, ⅜"-16 x 3¾"
Lock Washer, ⅜"
Hex Nut, ⅜"-16
25 GD16466 1 Bracket
26 G10152
G11391
G10230
G10104 2
2
2
1 Hex Head Cap Screw, ⅝"-11 x 9"
Flat Washer, ⅝" SAE
Lock Washer, ⅝"
Hex Nut, ⅝"-11
27 G10039
G10228
G10102 2
2
2 Hex Head Cap Screw, ½"-13 x 1¾"
Lock Washer, ½"
Hex Nut, ½"-13
28 --- - See “Hitch and Safety Chain” on page P53
29 GD16598
G10230
G10104 2
2
2 U-Bolt, 4" x 7" x ⅝"-11
Lock Washer, ⅝"
Hex Nut, ⅝"-11
30 G10599
G10622 4
4 Carriage Bolt, ⅜"-16 x 1¼"
Serrated Flange Nut, ⅜"-16
31 GA11961 2 Bracket (Manifold Hose)
32 G10062 2 Hex Head Cap Screw, ⅜"-16 x 3"
33 GD15867-06 4 Hose, 5" x 45"
34 GA11959 1 Support, Rear
35 GA11960 1 Support, Front
Vacuum Fan Mounting Brackets and Distribution Hoses
TM
Model 3200 M0241-02
6/11 P52
