Kinze 3200 Wing-Fold Planter Rev. 5/14 - Manual (Page 83)

Seed Rate Transmission Assembly and Driveline
ITEM PART NO. QTY.
(Per Assy.)
DESCRIPTION
10 GB0287 2 Coupler
11 GD5835 1 Shaft, ⅞" x 7"
12 GD2558 3 Lynch Pin, ¼"
13 GA7482
GA5146 1
1 Sprocket Storage Rod (EdgeVac)
Sprocket Storage Rod (Mechanical)
14 G10017
G10527
G10111 1
1
1
Hex Head Cap Screw, ½"-13 x 1½"
Lock Washer, ½", Internal/External
Lock Nut, ½"-13
15 GA5105
GA5106
GA5107
GA5108
GA5109
GA5110
GA5111
GA5112
GA5113 1
1
1
2
1
1
1
1
1
Sprocket, 15 Tooth
Sprocket, 17 Tooth
Sprocket, 19 Tooth
Sprocket, 23 Tooth
Sprocket, 24 Tooth
Sprocket, 25 Tooth
Sprocket, 26 Tooth
Sprocket, 27 Tooth
Sprocket, 28 Tooth
16 G10233 4 Machine Bushing, 1", 10 Gauge
17 GD11393-66
GD11393-78 2
-
Hex Shaft, ⅞" x 66" (3 Holes), 8 Row 36"/38"
Hex Shaft, ⅞" x 78" (3 Holes), 12 Row 30"
18 G10131 4 Square Head Set Screw, 5∕16"-18 x ¾"
19 GA5629
GA5116
GA5624
GD6551
G10640 1
3
1
4
-
Transmission Plate W/Bearings, Grease Fittings And Retaining Rings
Bearing, ⅞" Hex Bore, Cylindrical
Special Bearing, ⅞" Hex Bore x 1.6"
Ring
Grease Fitting, ¼"-28
20 GD7127 1 Shear Coupler
21 G10821
G10455 1 Clevis Pin, 3⁄16" x 2"
Cotter Pin, 1⁄16" x ½”
22 GD7822 1 Shaft, ⅞" x 7"
23 GA7336
GD7426
GD1026
G11387
G10229
G10047 1
-
-
-
-
-
Idler W/Bolt-On Sprockets
Sprocket, 12 Tooth
Sleeve, 13∕16" Long
Flat Washer, ⅜" SAE
Lock Washer, ⅜"
Hex Head Cap Screw, ⅜"-16 x 1¾"
24 G11396 1 Flat Washer, 1¼"
25 G3310-80
GR0912 1
-
Chain, No. 40, 80 Pitch Including Connector Link
Connector Link, No. 40
26 G10004
G10229
G10101 -
-
1
Hex Head Cap Screw, ⅜"-16 x 1¼"
Lock Washer, ⅜"
Hex Nut, ⅜"-16
27 GA2180 2 Hanger Bearing, ⅞" Hex Bore
28 GD11045 - Lock Clamp
29 G10130
G10923 -
-
Square Head Machine Bolt, 5∕16"-18 x 1¾"
Flange Nut, 5∕16"-18, No Serration
30 GD11394-63
GD11394-73
GD11394-79
GD11394-90 1
1
-
-
Hex Shaft, ⅞" x 63" (2 Holes), L.H., 8 Row 36"/38"
Hex Shaft, ⅞" x 73" (2 Holes), R.H., 8 Row 36"/38"
Hex Shaft, ⅞" x 79" (2 Holes), L.H., 12 Row 30"
Hex Shaft, ⅞" x 90" (2 Holes), R.H., 12 Row 30"
31 GD2962 2 Spring
32 G10880
G10110 3
3
Hex Head Cap Screw, ¼"-20 x 2¼"
Lock Nut, ¼"-20, Grade B
