ITEM PART NO. QTY. DESCRIPTION
1 GA13595
G1K411 1
-
Safety Chain W/Hook, ⅜"
Safety Chain Repair Kit, Includes: (1) Hook, (1) Flat Washer, (1) Latch Pin, (1) Safety
Latch, (1) Spring And (1) Retaining Ring
2 GB0156 1 Clevis
3 G10169
G10157 1
1 Hex Head Cap Screw, 1¼"-7 x 6"
Lock Nut, 1¼"-7
4 GA8097 1 Hitch Cap
5 G10036
G10230
G10104 1
1
1 Hex Head Cap Screw, ⅝"-11 x 4"
Lock Washer, ⅝"
Hex Nut, ⅝"-11
6 G10011
G10230
G10104 1
1
1 Hex Head Cap Screw, ⅝"-11 x 5½"
Lock Washer, ⅝"
Hex Nut, ⅝"-11
7 GD8260 1 Hose Holder
8 G11391
G10107 2
1 Flat Washer, ⅝" SAE
Lock Nut, ⅝"-11
9 GA5755 1 Pin, 2⅛" x 14"
10 A8048
G10641 1
-
Hitch W/Grease Fittings (Includes Items 4-7 And 11) (Non-Stock Item)
Grease Fitting, ⅛" NPT
11 G10108 3 Lock Nut, ⅜"-16
12 G11387 - Flat Washer, ⅜" SAE
13 GD5875 6 Hose Clamp, 9∕16" x 2½" x 2"
14 GA8318 1 Detent Pin W/Chain
15 G10028
GB0169
G10112 1
1
1 Hex Head Cap Screw, ¾"-10 x 3"
Bushing
Lock Nut, ¾"-10
16 --- - See “Row Marker Sequencing/Flow Control Valve” on page P91
17 GD7976 1 Bracket
18 G10019
G10232
G10106 2
2
2 Hex Head Cap Screw, 5∕16"-18 x 1"
Lock Washer, 5∕16"
Hex Nut, 5∕16"-18
19 GA13986
GA4995
GR0516
GR0515 1
-
-
-
Jack Assembly Complete
Detent Pin Assembly
Crank Assembly
Bevel Gear Set, Includes: (2) Bevel Gears, (1) Gear Pin, (1) Groove Pin
20 GA6798 1 Wrench
21 GD3180-23 - Sleeve, ⅝" I.D. x ⅞" O.D. x 33∕16" Long
22 GD2734-13 - Sleeve, 1¼" O.D. x 3⅛" Long
23 GA8312 - Pin W/Lynch Pin, 5 ½"
24 G10011
G10107 -
2
Hex Head Cap Screw, ⅝"-11 x 5½"
Lock Nut, ⅝"-11
25 G10028
G10231
G10105 12
12
12 Hex Head Cap Screw, ¾"-10 x 3"
Lock Washer, ¾"
Hex Nut, ¾"-10
26 G10001
G11387 2
2 Hex Head Cap Screw, ⅜"-16 x 1"
Flat Washer, ⅜" SAE
27 G10494
GD10646
G10157 1
1
1 Hex Head Cap Screw, 1 ¼"-7 x 3½"
Special Washer
Lock Nut, 1¼"-7
Hitch and Safety Chain
TM
Model 3200 M0241-02
