Kinze 3200 Wing-Fold Planter Rev. 5/14 - Manual (Page 79)

Two-Speed Point Row Clutch Drive
ITEM PART NO. QTY.
(Per Assy.)
DESCRIPTION
13 GA7336
GD7426
GD1026
G11387
G10229
G10047 1
-
-
-
-
-
Idler W/Bolt-On Sprockets
Sprocket, 12 Tooth
Sleeve, 13∕16" Long
Flat Washer, ⅜" SAE
Lock Washer, ⅜"
Hex Head Cap Screw, ⅜"-16 x 1¾"
14 GA7313 1 Sprocket Storage Rod
15 G10017
G10228
G10102 1
1
1 Hex Head Cap Screw, ½"-13 x 1½"
Lock Washer, ½"
Hex Nut, ½"-13
16 GA5114 3 Sprocket, 30 Tooth
17 GD11213 1 Spacer, 1¼" O.D. x 1¾" Long
18 GA7154 1 Sprocket W/Bearing, 18 Tooth
19 G10035
G11389
G10128
G10111 1
1
2
1 Hex Head Cap Screw, ½"-13 x 4"
Flat Washer, ½" SAE
Machine Bushing, ½", 14 Gauge
Lock Nut, ½"-13
20 --- - See “Two-Speed Point Row Clutch” on page P72
21 GD0914-6.25
GD0914-21.5 1
-
Hex Shaft, ⅞" x 6¼" (No Holes), 12 Row 30"
Hex Shaft, ⅞" x 21½" (No Holes), 8 Row 36"/38"
22 G10001
G10229
G10101 4
4
4 Hex Head Cap Screw, ⅜"-16 x 1"
Lock Washer, ⅜"
Hex Nut, ⅜"-16
23 GD11157 1 Spacer, 1½" O.D. x ⅝" Long
24 GA2180 2 Hanger Bearing, ⅞" Hex Bore
25 G10233 10 Machine Bushing, 1", 10 Gauge
26 G3310-76
GR0912 1
-
Chain, No. 40, 76 Pitch Including Connector Link
Connector Link, No. 40
27 GD5900-25 1 Sleeve, 2"
28 GD11045
G10233 2
4 Lock Clamp
Machine Bushing, 1", 10 Gauge
29 G3310-80
GR0912 1
-
Chain, No. 40, 80 Pitch Including Connector Link
Connector Link, No. 40
30 G10478
G10409 1
1 Clevis Pin, 5∕16" x 1"
Retaining Ring, 5∕16"
31 G3400-01 2 Flangette
32 G2100-03 1 Bearing, ⅞" Hex Bore, Spherical
33 G10303
G10232
G11386
G10106 3
3
3
3 Carriage Bolt, 5∕16"-18 x 1"
Lock Washer, 5∕16"
Flat Washer, 5∕16" SAE (As Required)
Hex Nut, 5∕16"-18
34 G3310-68
G3310-06
GR0912 1
-
-
Chain, No. 40, 68 Pitch Including Connector Link
Chain, No. 40, 6 Pitch Including Connector Link
Connector Link, No. 40
TM
Model 3200 M0241-02
6/11 P76
