Row Marker Assembly
ITEM PART NO. QTY.
(Per Assy.)
DESCRIPTION
7 GA8119
GA8076
G10641 1
-
-
Arm W/Grease Fitting, Second Stage, 60", 8 Row 36"/38"
Arm W/Grease Fitting, Second Stage, 72", 12 Row 30"
Grease Fitting, ⅛" NPT
8 G10159 - Washer, 1⅞"
9 GD15386
G10460 2
2 Pin, 1¼" x 7⅝"
Cotter Pin, ¼" x 2"
10 GD3214
G10460 1
2 Pin, 1¼" x 12¼"
Cotter Pin, ¼" x 2"
11 --- - See “Row Marker (Cushion) Cylinder” on page P89
12 GD5875 1 Hose Clamp, 9∕16" x 2½" x 2"
13 G10003
G10108 1
1 Hex Head Cap Screw, ⅜"-16 x 1½"
Lock Nut, ⅜"-16
14 GD0652
G10460 1
2 Pin, 1¼" x 9½"
Cotter Pin, ¼" x 2"
15 GA8073 1 Mount
16 G10879
G10230
G10104 4
2
2 Flanged 12 Point Bolt, ⅝"-11 x 2", Special Hardened
Lock Washer, ⅝"
Hex Nut, ⅝"-11
17 GA8074
G10641 1
-
Arm W/Grease Fittings, First Stage
Grease Fitting, ⅛" NPT
18 G10560
G10451 2
-
Clevis Pin, ½" x 1¾"
Cotter Pin, ⅛" x 1"
19 GD8218 1 Yoke
20 G10503 1 Hex Jam Nut, ⅝"-11, Grade 2
21 GD11115 1 Plain Yoke
22 G3302-08
G3302-07 1
1 Coil Chain, No. 9/0, 24 Links, 8 Row 36"/38"
Coil Chain, No. 9/0, 28 Links, 12 Row 30"
23 GD10674-03
GD10674-02 1
-
Chain Cover, 48", 8 Row 36"/38"
Chain Cover, 56", 12 Row 30"
24 GD2697
G10463 1
2 Pin, ⅞" x 11"
Cotter Pin, ¼" x 1½"
25 GD2971-11 1 Sleeve, 1 ⅞" Long
26 G10049
G10210
G10108 1
1
1 Hex Head Cap Screw, ⅜"-16 x 2½"
Washer, ⅜" USS
Lock Nut, ⅜"-16
27 GA8072 1 Linkage, 10"
28 G10862
G10107 1
2 Hex Head Cap Screw, ⅝"-11 x 3¼"
Lock Nut, ⅝"-11
29 GD21142
G10640
G11400
G10460 -
-
-
1
Marker Pin, 1¼" x 13/16"
Grease Fitting, ¼"-28
Retaining Ring, 1¼"
Cotter Pin, ¼" x 2"
30 GA11592 - Arm, First Stage
31 GD21143
G10640
G11400
G10460 -
-
-
1
Marker Pin, 1¼" x 9½"
Grease Fitting, ¼"-28
Retaining Ring, 1¼"
Cotter Pin, ¼" x 2"
