Page 99
ITEM
PART NO .
QTY .
DESCRIPTION
1
*G6400-06
GR1045
4
-
Connector W/O-Ring, 9⁄16"-18 Male JIC To O-Ring
O-Ring
2
GR1034
GR1035
1
-
Hex Socket Plug W/O-Ring
O-Ring
3
GR1032
GR1045
2
-
Port Adapter W/O-Ring
O-Ring
4
GR1033
1
Detent Spring
5
GR1036
2
Spring
6
GR1044
3
7⁄16
" Check Ball
7
GR1043
2
¼
" Steel Ball
8
---
-
Valve Body
(Non-Stock Item)
9
GR1047
GR1037
2
-
Hex Socket Plug W/O-Ring
O-Ring
10
---
-
Spool
(Non-Stock Item)
11
GR1042
2
Adjustment Screw
12
GR1048
2
Hex Jam Nut, ½"-20
13
GR1038
2
Needle
14
GR1039
2
Spring Pin
15
GR1046
2
Compression Spring
16
GR1040
2
O-Ring
17
GR1041
2
Teflon BU Ring
18
GA7341
1
Mount
19
GD7145
G10228
G10102
1
2
2
U-Bolt, 7" x 7" x ½"-13
Lock Washer, ½"
Hex Nut, ½"-13
20
G10001
G10229
2
2
Hex Head Cap Screw, ⅜"-16 x 1"
Lock Washer, ⅜"
A
GA5552
-
Valve Assembly Complete (Items 1-17)
B
GA5572
-
Flow Control Portion Only (Items 11-17)
*Not used on sizes with ⅜" hoses .
Row Marker Sequencing/Flow Control Valve and Mount
M0245-02
Model 3140
9/12
P96
