Kinze 3140 Stack Fold Planter Rev. 5/14 - Manual (Page 81)

Two-Speed Point Row Clutch Transmission and Module Drive
ITEM PART NO . QTY .
(Per Assy .)
DESCRIPTION
13 G10581
G10128
GD7889
G10228
G10102 1
1
1
1
1 Hex Head Cap Screw, ½"-13 x 2 ¼"
Machine Bushing, ½", 14 Gauge
Bushing, 1" O .D . x 9⁄16" I .D . x 7⁄16" Long
Lock Washer, ½"
Hex Nut, ½"-13
14 GA7154 2 Sprocket W/Bearing, 18 Tooth
15 GA6533 1 Idler Arm
16 GD5857 1 Spring
17 G10062
G11387
G10101 1
4
2 Hex Head Cap Screw, ⅜"-16 x 3"
Flat Washer, ⅜" SAE
Hex Nut, ⅜"-16
18 G10582
G11391
G10503 1
1
3 Hex Head Cap Screw, ⅝"-11 x 4", Full Thread
Flat Washer, ⅝" SAE
Hex Jam Nut, ⅝"-11, Grade 2
19 GD5860 1 Bar
20 G10602 - Spring Pin, ¼" x 1½"
21 GD10698 1 Input Shaft, ⅞" x 17½"
22 A7550
A7549
G10430
GD1255
G10546
G10470
GD10366
GA7317
GA7574 1
-
1
6
6
6
6
1
1
Overrunning Sprocket Assembly, R .H . (Non-Stock Item)
Overrunning Sprocket Assembly, L .H . (Non-Stock Item)
External Retaining Ring, 1¼"
L-Pin
Spring Pin, 3⁄16" x 1¼"
Cotter Pin, 5⁄32" x 1"
Spring
Block
Sprocket W/Bushing, 34 Tooth
23 GD7127 1 Shear Coupler
24 G10462 1 Cotter Pin, 3⁄16" x 2"
25 GA5548 1 Special Bearing
26 GD10336 1 Shaft, ⅞" x 11"
27 G10007
G11391
G10230
G10104 1
1
1
1 Hex Head Cap Screw, ⅝"-11 x 1½"
Flat Washer, ⅝" SAE
Lock Washer, ⅝"
Hex Nut, ⅝"-11
28 GD10696 1 Mounting Angle
29 GD1114
G10230
G10104 1
2
2 U-Bolt, 7" x 7" x ⅝"-11
Lock Washer, ⅝"
Hex Nut, ⅝"-11
30 GA7571
GA7570 1
-
Transmission Bracket, L .H . (Shown)
Transmission Bracket, R .H .
31 GD10109 1 Coupler, 6"
32 G10397
G10128
GB0258
G10228
G10102 1
1
1
1
1 Hex Head Cap Screw, ½"-13 x 2¾"
Machine Bushing, ½", 14 Gauge
Stepped Spacer, ⅞"
Lock Washer, ½"
Hex Nut, ½"-13
33 GA5114 1 Sprocket, 30 Tooth
34 G3310-224
GR0912 2
-
Chain, No . 40, 224 Pitch Including Connector Link
Connector Link, No . 40
35 GA5109
GA5105
GA5106
GA5112
GA5108
GA5110
GA5111 1
1
1
1
-
-
-
Sprocket, 24 Tooth
Sprocket, 15 Tooth
Sprocket, 17 Tooth
Sprocket, 27 Tooth
Sprocket, 23 Tooth (From Transmission)
Sprocket, 25 Tooth (From Transmission)
Sprocket, 26 Tooth (From Transmission)
A G1K269 - Lock Clamp Kit (Items 8 And 9)
