Center Drop Assembly and Driveline
ITEM PART NO . QTY . DESCRIPTION
28 GA8002
GA8045
GR1365
GR1294
GR1352
GR1300
GR1301 2
-
-
-
-
-
-
U-Joint W/Grease Fitting, Female, 66⅜", 12 Row 30"
U-Joint W/Grease Fitting, Female, 82½", 12 Row 36"/38"/40" And 16 Row 30"
Yoke, ⅞" Hex
Cross And Bearing Kit
Inboard Yoke
Grease Fitting, 67 .5°, Metric
Spring Pin, 8 mm x 50 mm
29 GA8001
GR1365
GR1294
GR1295
GR1300
GR1301 2
-
-
-
-
-
U-Joint W/Grease Fitting, Male, 4013⁄32"
Yoke, ⅞" Hex
Cross And Bearing Kit
Inboard Yoke
Grease Fitting, 67 .5°, Metric
Spring Pin, 8 mm x 50 mm
30 GD10521
GD10520 1
-
Angle, L .H .
Angle, R .H .
31 GD10343 2 Mount
32 GD5212
GD9378 2
-
Coupler, 1¾", 12 Row 30" And 16 Row 30"
Coupler, 12", 12 Row 36"/38"/40"
33 GA5114 - Sprocket, 30 Tooth (Machines With Point Row Clutches)
34 GD1256 2 Spring
35 G10453 2 Cotter Pin, 3⁄16" x 1"
36 GA0378 1 Block And Hub Assembly
37 GD1255 2 L-Pin
38 GA5165 1 Sprocket, 30 Tooth
39 G10430 1 External Retaining Ring, 1¼"
40 . G10131 8 Square Head Set Screw, 5⁄16"-18 x ¾"
41 GD16205 1 Spacer
42 GD16209 2 Extension
A GA9843
GA5164 -
- Ratchet/Sprocket Assembly (Items 34-39) (Shown)
Ratchet/Sprocket Assembly (Items 34-39)
TM
Model 3140 M0245-02
P81 9/12
