Kinze 3140 Stack Fold Planter Rev. 5/14 - Manual (Page 111)

M0245-02 Model 3140
9/12 P108
TM
ITEM PART NO . QTY . DESCRIPTION
1 GD13659 2 Light Bracket Mount
2 GA9507
GA9508
GA5385
-
-
-
Wiring Harness W/7 Terminal Female Connector, 186", 12 Row 30” (4 Light Connections)
Wiring Harness W/7 Terminal Female Connector, 210", 12 Row 36”/38”/40” And 16
Row 30” (4 Light Connections)
7 Terminal Female Connector
3 G1K248 - 3-Pin Female Connector Kit (Black), Includes: (3) 3-Pin Female Housings, (9) Pin
Contacts, (9) Seals
4 G1K252 - 3-Pin Male Connector Kit (Black), Includes: (3) 3-Pin Male Housings, (9) Socket
Contacts, (9) Seals
5 GD11089 - Sealing Plug
6 GA8047 - Dust Plug (Black)
7 GA6699
GA6700
GR1956
GR1957
GR1958
GR1208 1
1
-
-
-
-
Double Light Assembly
Double Light Assembly (Shown)
Amber Lens Kit, Includes: (1) Amber Lens, (1) Gasket, and (3) Hex Head Cap Screws
Red Lens Kit, Includes: (1) Red Lens, (1) Gasket, and (3) Hex Head Cap Screws
Black Cover Kit, Includes: (1) Black Cover, (1) Gasket, and (3) Hex Head Cap Screws
Bulb
8 GD9707
GD9708 1
-
Light Bracket, L .H . (Shown)
Light Bracket, R .H .
9 GA6701
GR1956
GR1208 2
-
-
Single Amber Light Assembly
Amber Lens Kit, Includes: (1) Amber Lens, (1) Gasket, and (3) Hex Head Cap Screws
Bulb
10 GD16182 2 Light Bracket
11 GD7145
G10228
G10102 2
4
4 U-Bolt, 7" x 7" x ½"-13
Lock Washer, ½"
Hex Nut, ½"-13
12 G10064
G11385
G10110 -
-
- Hex Head Cap Screw, ¼"-20 x 1"
Flat Washer, ¼” SAE
Lock Nut, ¼"-20, Grade B
13 G11048
G10108 -
- Hex Head Cap Screw, ⅜"-16 x 7½"
Lock Nut, ⅜"-16
14 G10017
G10228
G10102 4
4
4 Hex Head Cap Screw, ½"-13 x 1½"
Lock Washer, ½"
Hex Nut, ½"-13
Electrical Components and Light Brackets
