ITEM PART NO . QTY .
(Per Assy .)
DESCRIPTION
1 GD10635
G10103
G10227
GD10282 1
2
2
2 Threaded Rod, ¼"-20 x 3½"
Hex Nut, ¼"-20
Lock Washer, ¼"
Allen Nut, ¼"-20
2 GD10123 2 Spring
3 GA8393
GR1306
GR1303
GR1304
GR1305 2
-
-
-
-
Solenoid Complete
Snap Ring
Spring
Boot
Plunger
4 GD10103 1 Mounting Plate
5 GD10586 1 Bushing
6 GA7463
GD10584
G10873
G10872
G10804
G10765
GD10120 1
-
-
-
-
-
-
Hub/Sleeve Assembly W/Seals, Sleeve, Pins And Screws
Sleeve
Hex Socket Set Screw, 5⁄16"-18 x ¾"
Hex Socket Set Screw, 5⁄16"-18 x ¼"
Spring Pin, 5⁄32" x ⅞"
Spring Pin, ¼" x 1"
Seal
7 GA9571
GD10120 1
-
Hub W/Seal
Seal
8 GD9671 2 Spring, L .H .
9 GD10585 2 Stop Collar
10 GA9572
GD10120 1
-
Hub W/Seal
Seal
11 G10023
G10227
G10103 1
1
1 Hex Head Cap Screw, ¼"-20 x ¾"
Lock Washer, ¼"
Hex Nut, ¼"-20
12 GD10636
G10108
G10229
G10101 1
2
2
2 Threaded Rod, ⅜"-16 x 4¼"
Lock Nut, ⅜"-16
Lock Washer, ⅜"
Hex Nut, ⅜"-16
13 GD10510 2 Actuator Arm
14 GD11120 2 Rue Ring Cotter, 5⁄16"
15 G10857
G10227 3
3 Hex Head Cap Screw, ¼"-20 x 1¼"
Lock Washer, ¼"
16 GD10694
GD10693 1
-
Shaft, R .H . Threads (Shown)
Shaft, L .H . Threads
17 GD10638
GD10587 1
-
Coupler W/R .H . Threads (Shown)
Coupler W/L .H . Threads
18 G10496 2 External Inverted Snap Ring, 1½"
19 GD10698 1 Input Shaft, ⅞" x 17½"
20 G10859 1 Spring Pin, 3⁄16" x 2¼"
21 G10876 3 Hex Socket Head Screw, No . 10-32 x ¼"
22 GD10673 1 Sprocket, 34 Tooth
23 G10374 3 Hex Socket Head Screw, ¼"-20 x 1"
24 GA7274 1 Jumper Wire W/Ring Terminals, 23⁄16"
25 GD14513 2 Felt Washer
26 GD9672 - Spring, R .H .
Two-Speed Point Row Clutch
M0245-02 Model 3140
9/12 P74
