Kinze 3140 Stack Fold Planter Rev. 5/14 - Manual (Page 87)

ITEM PART NO . QTY .
(Per Assy .)
DESCRIPTION
1 GA4353
G10641 1
-
Arm W/Grease Fittings, Second Stage, 110", 12 Row 30"
Grease Fitting, ⅛" NPT
2 G11396
G10159
G10322 -
-
- Flat Washer, 1¼" SAE (As Required)
Machine Bushing, 1¼", 10 Gauge (As Required)
Machine Bushing, 1¼", 18 Gauge (As Required)
3 GD2161
G10460 1
2 Pin, 1¼" x 8¼"
Cotter Pin, ¼" x 2"
4 GA11766
G10640
G10460 -
-
- Pin W/Grease Fitting, 1¼" x 1113⁄16"
Grease Fitting, ¼"-28
Cotter Pin, ¼" x 2"
5 GA11591 - Arm, First Stage
6 GD0752-41 4 Sleeve, 1"
7 G10008
G11391
G10230
G10104 4
8
4
4 Hex Head Cap Screw, ⅝"-11 x 2"
Flat Washer, ⅝" SAE
Lock Washer, ⅝"
Hex Nut, ⅝"-11
8 --- - See "Row Marker (Cushion) Cylinder" on page P90
9 GD15386
G10460 1
1 Pin, 1¼" x 7⅝"
Cotter Pin, ¼" x 2"
10 GD5892 1 Hose Clamp, ⅝" x 1½" x 1½"
11 G10133
G10232
G10106 1
1
1 Hex Head Cap Screw, 5⁄16"-18 x 1½"
Lock Washer, 5⁄16"
Hex Nut, 5⁄16"-18
12 GA11767
G10640
G10460 -
-
- Pin W/Grease Fitting, 1¼" x 9½"
Grease Fitting, ¼"-28
Cotter Pin, ¼" x 2"
13 GA5130 1 Mount
14 GA7347 1 Mount
15 GD8175
G11391
G10230
G10104 2
4
4
4 U-Bolt, 7" x 7" (Diamond) x ⅝"-11
Flat Washer, ⅝" SAE
Lock Washer, ⅝"
Hex Nut, ⅝"-11
16 GD0453-07 1 Extension Tube, 45", 12 Row 30"
17 GD2721
G10228
G10102 1
2
2 U-Bolt, 2" x 2" x ½"-13
Lock Washer, ½"
Hex Nut, ½"-13
Row Marker Assembly, Two-Fold Low Profile, 12 Row 30"
M0245-02 Model 3140
9/12 P84
