Kinze 3140 Stack Fold Planter Rev. 5/14 - Manual (Page 119)

M0245-02 Model 3140
Rev . 5/13 P116
TM
FRONT SHAFT 7100-209 DRIVER
REAR SHAFT DRIVEN LEFT SIDE TRANSMISSION
EdgeVac ®
PROTECTED BY THE FOLLOWING PATENTS
UNITED STATES
7,093,548 7,152,542
7100-456
ITEM PART NO . QTY . DESCRIPTION
1 G7100-392 2 Decal, Caution
2 G7100-456 2 Decal, EdgeVac
3 G7100-209
G7100-210 1
1 Decal, Transmission, L .H . Side
Decal, Transmission, R .H . Side
Fan can start at any time.
Operating fan can blow debris
and has a high noise level.
Always wear eye and hearing
protection when working
around fan.
7100-392
CAUTION
1
2
G7100-385
Uncontrolled machine movement
can crush resulting in death,
serious injury, or damage to
property and equipment.
Install safety lockup devices
before working under or
transporting this equipment.
7100-385
WARNING
Part No .: G7100-385
Description: Decal, Warning
Part No .: GD2199
Description: SMV Sign
3
Decals, Paint, and Miscellaneous
