Kinze 3140 Stack Fold Planter Rev. 5/14 - Manual (Page 61)

ITEM PART NO . QTY .
(Per Assy .)
DESCRIPTION
1 --- - See "Seed Rate Transmission and Module Drive Assembly" on page P65
2 GD8175
G11391
G10230
G10104 2
4
4
4 U-Bolt, 7" x 7" (Diamond) x ⅝"-11
Flat Washer, ⅝" SAE
Lock Washer, ⅝"
Hex Nut, ⅝"-11
3 G10005
G11391
G10230
G10104 4
4
4
4 Hex Head Cap Screw, ⅝"-11 x 1¾"
Flat Washer, ⅝" SAE
Lock Washer, ⅝"
Hex Nut, ⅝"-11
4 GA7294
GD5804
GA7295
G10641
G10610 1
1
1
-
-
Arm W/Pin, Lower Clamp And Spring Pins
Pin, 1¼" x 12"
Clamp W/ Grease Fittings
Grease Fitting, ⅛" NPT
Spring Pin, ⅜" x 2"
5 G10026
G11392
G10231 2
2
2 Hex Head Cap Screw, ¾"-10 x 2"
Flat Washer, ¾" SAE
Lock Washer, ¾"
6 GD10403 2 Concentric Spacer
7 GD10328 1 Adjustment Block
8 GA4705
G10117 1
2 Adjusting Screw
Hex Nut, 1"-8
9 GD7041
G11394
G10459 1
2
2 Pin, 1" x 4"
Flat Washer, 1" SAE
Cotter Pin, 3⁄16" x 1½"
10 G10026
G10231 2
2 Hex Head Cap Screw, ¾"-10 x 2"
Lock Washer, ¾"
11 G11081 - Hex Jam Nut, 1½"-12, Grade 2
12 GA0895 2 Bearing
13 GA2148
GR0434 1
-
Hub W/Cups, 6 Bolt
Cup
14 GR0270 6 Lug Bolt, 9⁄16"-18
15 GA2558
GD11490 1
-
Spindle W/Round External Retaining Ring, 9½"
Round External Retaining Ring
16 GD0844 1 Tire, 7 .60" x 15", 8 Ply (Specify Brand*)
17 GA5196 1 Wheel W/Valve Protector, 5" x 15"
18 GD1166 1 Valve Stem
A GA2147 - Hub And Spindle Assembly (Items 11, 12, 13, and 15)
B GA10660
GA10661
-
-
Ground Drive And Contact Wheel Assembly, R .H . (Items 1-18 On This Page, Items
2-15 On Pages P52 And P53, Items 1-10 And 12-40 On Pages P58 And P59 and
Items 2-13 And 15-20 On Pages P60 And P61)
Ground Drive And Contact Wheel Assembly, L .H . (Items 1-18 On This Page, Items
2-15 On Pages P52 And P53, Items 1-10 And 12-40 On Pages P58 And P59 and
Items 2-13 And 15-20 On Pages P60 And P61)
* Specific brand requests will be supplied only as available from current Kinze Repair Parts stock . If a specific brand
requested is not in stock, the brand available will be supplied .
Ground Drive Wheel Assembly
M0245-02 Model 3140
9/12 P58
