Kinze 3140 Stack Fold Planter Rev. 5/14 - Manual (Page 67)

ITEM PART NO . QTY .
(Per Assy .)
DESCRIPTION
1 --- - See "Dual Lift Assist Wheel Package Hydraulic System" on page P102 or
See "Dual Lift Assist Wheel Package and Wing Down Flex Cylinder Package
Hydraulic System" on page P105
2 --- - See "Dual Lift Assist Cylinder" on page P92
3 G10059
GD2169
G10105
2
2
2
Hex Head Cap Screw, ¾"-10 x 9½"
Special Washer, 25/32" I .D . x 1¼" O .D ., Hardened
Hex Nut, ¾"-10
4 GA7867 - Clamp
5 GA7860 - Mount
6 G10028
GD2169
G10105
3
3
3
Hex Head Cap Screw, ¾"-10 x 3"
Special Washer, 25/32" I .D . x 1¼" O .D ., Hardened
Hex Nut, ¾"-10
7 GD8311
G10460
2
4
Pin, 1¼" x 10½"
Cotter Pin, ¼" x 2"
8 GA7345
G10641
G10343
1
1
1
Lift Assist Frame W/Grease Fittings
Grease Fitting, ⅛" NPT
Grease Fitting, 90°, ⅛"-27
9 GA8174 1 Lockup W/Pin
10 GA6455 1 Roller Ring, L .H .
11 G10008
GB0218
G11391
G10230
G10104
2
2
4
2
2
Hex Head Cap Screw, ⅝"-11 x 2"
Bushing, 21/32" I .D . x ⅞" O .D . x 19⁄32" Long
Flat Washer, ⅝" SAE
Lock Washer, ⅝"
Hex Nut, ⅝"-11
12 G10007
GB0218
G11391
G10230
GD9179
2
2
4
2
2
Hex Head Cap Screw, ⅝"-11 x 1½"
Bushing, 21/32" I .D . x ⅞" O .D . x 19⁄32" Long
Flat Washer, ⅝" SAE
Lock Washer, ⅝"
Sleeve
13 GD9170 1 Roller
14 G10032
G10228
G10102
1
1
1
Hex Head Cap Screw, ½"-13 x 3¾"
Lock Washer, ½"
Hex Nut, ½"-13
15 GD9208 1 Spring
16 G10713
G11388
G10113
1
2
1
Hex Head Cap Screw, 7⁄16"-14 x 6"
Flat Washer, 7⁄16" SAE
Lock Nut, 7⁄16"-14
17 GA6454 1 Roller Ring, R .H .
18 G10234 2 Machine Bushing, 2⅛", 10 Gauge
19 GA6443 1 Caster Wheel Arm
20 G10026
G10231
2
2
Hex Head Cap Screw, ¾"-10 x 2"
Lock Washer, ¾"
21 G11081 2 Hex Jam Nut, 1½"-12, Grade 2
22 GA0895 2 Bearing
23 GA2148
GR0434
1
-
Hub W/Cups, 6 Bolt
Cup
24 GR0270 6 Lug Bolt, 9⁄16"-18
25 GA2558
GD11490
1
-
Spindle W/Round External Retaining Ring, 9½"
Round External Retaining Ring
26 GD0844 1 Tire, 7 .60" x 15", 8 Ply (Specify Brand*)
27 GA5196 1 Wheel W/Valve Protector, 5" x 15"
28 GD1166 1 Valve Stem
29 GA8768 2 Clamp, 3"
30 GA8769 1 Accumulator, 16 Row 30"
31 GD11814 2 Clamp, 16 Row 30"
32 GD11813 2 Mount, 16 Row 30"
33 G10687
G10108
2
2
Hex Head Cap Screw, ⅜"-16 x 5½"
Lock Nut, ⅜"-16
34 G10756
G10108
2
2
Hex Head Cap Screw, ⅜"-16 x 6"
Lock Nut, ⅜"-16
A GA2147 - Hub And Spindle Assembly (Items 21, 22, 23, and 25)
* Specific brand requests will be supplied only as available from current Kinze Repair Parts stock . If a specific brand
requested is not in stock, the brand available will be supplied .
Dual Lift Assist Wheels
M0245-02 Model 3140
9/12 P64
