ITEM PART NO . QTY . DESCRIPTION
1 --- - Hydraulic Latch, See “Wing Assembly” on page P53
2 G6400-06-04
GR1465 2
-
Connector W/O-Ring, 9⁄16"-18 Male JIC To 7⁄16"-20 O-Ring
O-Ring
3 *A1188
*A1103 2
-
Hose Assembly, ¼" x 66", 12 Row 30"
Hose Assembly, ¼" x 110", 12 Row 36"/38"/40" And 16 Row 30"
4 G6801-06-08
GR1037
G6400-06-08
GR1037 2-4
-
2
-
Elbow W/O-Ring, 90°, 9⁄16"-18 Male JIC To ¾"-16 O-Ring
O-Ring
Connector W/O-Ring, 9⁄16"-18 Male JIC To ¾"-16 O-Ring
O-Ring
5 --- - See “Wing Fold Cylinder, 12 Row 30”” on page P89
or
See “Wing Fold Cylinder, 12 Row 36”/38”/40” and 16 Row 30”” on page P89
6 G6500-06 6 Swivel Elbow, 90°, 9⁄16"-18 Male JIC To Female
7 G6602-06 2 Swivel Tee, 9⁄16"-18 JIC
8 *A1113
*A1170 4
-
Hose Assembly, ¼" x 80", 12 Row 30"
Hose Assembly, ¼" x 90", 12 Row 36"/38"/40" And 16 Row 30"
9 G306-06 2 Lock Nut, 9⁄16"-18
10 G2703-06 2 Bulkhead Tee, 9⁄16"-18 Male JIC
11 *A1198 2 Hose Assembly, ¼" x 60"
12 GD4086 2 ISO Coupler
13 *A1113
*A1102 2
-
Hose Assembly, ¼" x 80", 12 Row 30"
Hose Assembly, ¼" x 95", 12 Row 36"/38"/40" And 16 Row 30"
* Hydraulic hose is not stocked by Kinze Repair Parts, but can be made available on a special order basis . Call for quote .
Fold Hydraulic System
M0245-02 Model 3140
9/12 P100
