Kinze 3140 Stack Fold Planter Rev. 5/14 - Manual (Page 57)

Wing Assembly
ITEM PART NO . QTY . DESCRIPTION
1 GA7346 2 Catch
2 G10039
G11389
G10228
G10102 8
8
8
8 Hex Head Cap Screw, ½"-13 x 1¾"
Flat Washer, ½" SAE
Lock Washer, ½"
Hex Nut, ½"-13
3 GD10432
GD10433 1
1 Shim, 1¼" x 4½", 22 Gauge (As Required)
Shim, 1¼" x 4½", 16 Gauge (As Required)
4 G10003
G10229 8
8 Hex Head Cap Screw, ⅜"-16 x 1½"
Lock Washer, ⅜"
5 GA7383 2 Hydraulic Latch
6 G10047
G10003
G10229 -
-
- Hex Head Cap Screw, ⅜"-16 x 1¾"
Hex Head Cap Screw, ⅜"-16 x 1½"
Lock Washer, ⅜"
7 GD5892 - Hose Clamp, ⅝" x 1½" x 1½"
8 GD10378 4 Bronze Bushing, 3"
9 G10025
GD9052 2
2 Hex Head Cap Screw, ¾"-10 x 1½"
Special Washer, ¾" I .D . x 2" O .D ., Hardened
10 GD10449 4 Hook
11 GD10555 2 Sleeve
12 G10871
G10111 2
2 Hex Head Cap Screw, ½"-13 x 6"
Lock Nut, ½"-13
13 GD10556 2 Pin, ⅝" x 6¾"
14 GD10532 2 Sleeve
15 GA6497
G10640 2
-
Cam Follower W/Grease Fitting
Grease Fitting, ¼"-28
16 GA7329
GA7328
GA7807
GA7806
GA7361
GA7360
G10112
GD2558 1
1
1
1
1
1
4
4 Wing, L .H ., 90¾", 12 Row 30" (Shown)
Wing, R .H ., 90¾", 12 Row 30"
Wing, L .H ., 100", 12 Row 36"/38"
Wing, R .H ., 100", 12 Row 36"/38"
Wing, L .H ., 117", 12 Row 38"/40" And 16 Row 30"
Wing, R .H ., 117", 12 Row 38"/40" And 16 Row 30"
Lock Nut, ¾"-10
Lynch Pin, ¼"
17 G10001
G10108 2
2 Hex Head Cap Screw, ⅜"-16 x 1" (Hook Stop)
Lock Nut, ⅜"-16
18 G10027
G11392 4
4 Hex Head Cap Screw, ¾"-10 x 2½"
Flat Washer, ¾" SAE
19 GD10379 2 Sleeve, 2½"
20 GA7326
GA7357 2
-
Link Assebmly, 71¼", 12 Row 30"
Link Assebmly, 87½", 12 Row 36"/38"/40" And 16 Row 30"
21 GD10478 2 End Cap
22 GD10741
GD11155 -
- Shim ( .015") (As Required)
Shim ( .060") (As Required)
23 G10763 8 Grease Fitting, Extended, ⅛"-27
24 G10039
G10228 16
16 Hex Head Cap Screw, ½"-13 x 1¾"
Lock Washer, ½"
M0245-02 Model 3140
9/12 P54
TM
