Kinze 3140 Stack Fold Planter Rev. 5/14 - Manual (Page 89)

ITEM PART NO . QTY .
(Per Assy .)
DESCRIPTION
1 GA7116
GA7118 1
-
Arm, Second Stage, 138¼", 12 Row 36"/38"/40"
Arm, Second Stage, 172¼", 16 Row 30"
2 GD1701
G10460 1
2 Pin, 1¼" x 6½"
Cotter Pin, ¼" x 2"
3 G10322
G10159 4
-
Machine Bushing, 1¼", 18 Gauge
Machine Bushing, 1¼", 10 Gauge (As Required)
4 GA11768
G10640
G10460 -
-
- Pin W/Grease Fitting, 1¼" x 13"
Grease Fitting, ¼"-28
Cotter Pin, ¼" x 2"
5 GA11596 - Arm, First Stage
6 --- - See "Row Marker (Cushion) Cylinder" on page P90
7 G10133
G10232
G10106 1
1
1 Hex Head Cap Screw, 5⁄16"-18 x 1½"
Lock Washer, 5⁄16"
Hex Nut, 5⁄16"-18
8 GD5875 1 Hose Clamp, 9⁄16" x 2½" x 2"
9 G10008
G10230
G10104 4
4
4 Hex Head Cap Screw, ⅝"-11 x 2"
Lock Washer, ⅝"
Hex Nut, ⅝"-11
10 GD0652
G10460 1
2 Pin, 1¼" x 9½"
Cotter Pin, ¼" x 2"
11 GA7415 1 Mount
12 GA11769
G10640
G10049
G10108 -
-
-
- Pin W/Grease Fitting, 1¼" x 11½"
Grease Fitting, ¼"-28
Hex Head Cap Screw, ⅜"-16 x 2½"
Lock Nut, ⅜"-16
13 GD1114
G10230
G10104 2
4
4 U-Bolt, 7" x 7" x ⅝"-11
Lock Washer, ⅝"
Hex Nut, ⅝"-11
14 GD10577 1 Plate, 7" x 11½"
15 GD2721
G10228
G10102 3
6
6 U-Bolt, 2" x 2" x ½"-13
Lock Washer, ½"
Hex Nut, ½"-13
16 GA7354 - Stand, R .H .
17 GA7353 1 Stand, L .H .
18 G10017
G10228
G10102 2
2
2 Hex Head Cap Screw, ½"-13 x 1½"
Lock Washer,
1 /
2
"
Hex Nut, ½"-13
19 GA9088 1 Molded Stop, 12¼" Long
20 GD15723 - Shim, 2" x 15", 16 Gauge (As Required)
21 GD0453-10
GD0453-09
GD0453-03 -
1
-
Extension Tube, 73", 12 Row 36"/38"
Extension Tube, 75", 12 Row 38"/40"
Extension Tube, 50", 16 Row 30"
22 G11396
G10322 2
2 Flat Washer, 1¼" SAE
Machine Bushing, 1¼", 18 Gauge
Row Marker Assembly, Two-Fold Low Profile
12 Row 36"/38"/40" and 16 Row 30"
M0245-02 Model 3140
9/12 P86
