Kinze 3140 Stack Fold Planter Rev. 5/14 User Manual
Page 63
ITEM
PART NO .
QTY .
(Per Assy .)
DESCRIPTION
1
---
-
See "Module Drive" on page P67
2
GA7297
1
Arm
3
GD2558
1
Lynch Pin, ¼"
4
G10233
-
Machine Bushing, 1", 10 Gauge
5
GA2068
2
Spring W/Plug
6
G3310-218
G3310-224
GR0912
1
1
-
Chain, No . 40, 218 Pitch Including Connector Link (Used With 15 And 19 Tooth Sprockets)
Chain, No . 40, 224 Pitch Including Connector Link (Used With 30 Tooth Sprocket)
Connector Link, No . 40
7
GA5105
GA5107
GA5114
-
-
1
Sprocket, 15 Tooth
Sprocket, 19 Tooth
Sprocket, 30 Tooth
8
G10861
G11389
G10501
2
2
2
Hex Head Cap Screw, ½"-13 x 5", Full Thread
Flat Washer, ½" SAE
Hex Jam Nut, ½"-13, Grade 2
9
GD10329
1
Shaft
10
GA5090
GD5753
GD5752
1
1
1
Tire And Rim Assembly (Specify Brand*)
Tire, 4 .10" x 6" (Specify Brand*)
Inner Tube
11
G10602
2
Spring Pin, ¼" x 1½"
12
G10303
G10232
G10106
6
6
6
Carriage Bolt, 5⁄16"-18 x 1"
Lock Washer, 5⁄16"
Hex Nut, 5⁄16"-18
13
GA9846
-
Flanged Bearing, ⅞" Hex Bore
14
GD10332
1
Shaft, ⅞" x 11"
15
G10005
G11391
GD3180-15
G10107
1
1
1
1
Hex Head Cap Screw, ⅝"-11 x 1¾"
Flat Washer, ⅝" SAE
Sleeve, ⅝" I .D . x ⅞" O .D . x 15⁄32" Long
Lock Nut, ⅝"-11
* Specific brand requests will be supplied only as available from current Kinze Repair Parts stock . If a specific brand
requested is not in stock, the brand available will be supplied . Different brand tires may have different diameters .
Change in tire brand may affect rates . Field checks are recommended after any change in contact tires .
Contact Wheel Assembly
M0245-02
Model 3140
9/12
P60
TM
