Kinze 3140 Stack Fold Planter Rev. 5/14 User Manual
Page 55
ITEM
PART NO .
QTY .
DESCRIPTION
1
GD9750
2
Pin, 11¾" Long, Category 2 - Lower Hitch
2
GD10418
2
Bushing, Category 2
3
G10151
G10396
1
1
Hex Head Cap Screw, 1"-8 x 6", Category 2 - Upper Hitch
Lock Nut, 1"-8
4
G10048
G10108
2
2
Hex Head Cap Screw, ⅜"-16 x 2"
Lock Nut, ⅜"-16
5
GD2558
2
Lynch Pin, ¼"
6
GD10419
2
Top Link Bushing, Category 2
7
GD10450
G10159
G11396
G10460
6
12
-
12
Pin, 1¼" x 11¼"
Machine Bushing, 1¼", 10 Gauge
Flat Washer, 1¼" SAE
Cotter Pin, ¼" x 2"
8
GA7349
GA7359
G10641
2
2
-
Arm W/Grease Fittings, 74", 12 Row 30"
Arm W/Grease Fittings, 93½", 12 Row 36"/38"/40" And 16 Row 30"
Grease
Fitting, ⅛" NPT
9
G10689
G11391
G10107
1
1
1
Carriage Bolt, ⅝"-11 x 2"
Flat Washer, ⅝" SAE
Lock Nut, ⅝"-11
10
GD10456
1
Hose Holder
11
GD10486
G10159
G10460
GD10737
G10403
G10110
2
4
4
2
2
2
Pin, 1¼" x 9", 12 Row 30"
Machine Bushing, 1¼", 10 Gauge
Cotter Pin, ¼" x 2"
Pin, 1¼" x 7⅞", 12 Row 36"/38"/40" And 16 Row 30"
Hex Head Cap Screw, ¼"-20 x 2½"
Lock Nut, ¼"-20, Grade B
12
---
-
See "Fold Hydraulic System" on page P99
13
---
-
14
GA4666
GD2557
1
1
Pin, 1¼" x 4½", Category 3 - Upper Hitch
Lynch Pin, 7⁄16"
15
GD9333
GD2557
2
4
Pin, 17⁄16" x 8¾", Category 3 - Lower Hitch
Lynch Pin, 7⁄16"
16
A7331
A7804
G10640
1
1
4
Center Toolbar W/Grease Fittings, 7" x 7" x 167", 12 Row 30"
(Non-Stock Item)
Center Toolbar W/Grease Fittings, 7" x 7" x 226", 12 Row 36"/38"/40" And 16 Row
30"
(Non-Stock Item) (Shown)
Grease Fitting, ¼"-28
17
GA7466
2
Detent Pin W/Chain
18
G10585
G10111
2
2
Hex Head Cap Screw, ½"-13 x 3¼"
Lock Nut, ½"-13
19
GA7334
2
Mount
20
GD1114
G10230
G10104
4
8
8
U-Bolt, 7" x 7" x ⅝"-11
Lock Washer, ⅝"
Hex Nut, ⅝"-11
21
GA7467
2
Parking Stand
A
G1K231
-
Category 3 To Category 2 Conversion Kit (Items 1-6)
Center Frame Assembly
M0245-02
Model 3140
9/12
P52
