Kinze 3140 Stack Fold Planter Rev. 5/14 - Manual (Page 53)

M0245-02 Model 3140
9/12 P50
TM
Manifolds and Distribution Hoses
ITEM PART NO . QTY . DESCRIPTION
1 GD2200 1 SMV Mount
2 GD15867-09
GD15867-10
GD15867-11 2
-
-
Hose, 5" x 120", 12 Row 30"
Hose, 5" x 138", 12 Row 36"/38"/40"
Hose, 5" x 144", 16 Row 30"
3 G11188 4 T-Bolt Clamp, 5¼"
4 GD15833
G10229
G10101 6
12
12
U-Bolt, 5" Diameter x ⅜"-16
Lock Washer, ⅜"
Hex Nut, ⅜"-16
5 GA12217
GA12216
GA12229
GA12228
GA12233
GA12232 1
-
-
-
-
-
Manifold, Outside, R .H ., 45", 12 Row 30"
Manifold, Outside, R .H ., 45", 12 Row 30"
Manifold, Outside, R .H ., 61½", 12 Row 36"/38"/40"
Manifold, Outside, R .H ., 61½", 12 Row 36"/38"/40"
Manifold, Outside, R .H ., 66¾", 16 Row 30"
Manifold, Outside, R .H ., 66¾", 16 Row 30"
6 GD7145
G11389
G10228
G10102 -
-
-
- U-Bolt, 7" x 7" x ½"-13
Flat Washer, ½" SAE
Lock Washer, ½"
Hex Nut, ½"-13
7 GA11107 3 Manifold Support, L .H .
8 GA11106 3 Manifold Support, R .H .
9 GD16251 4 Gasket
10 GD17423-01 - Sleeve, 5" x 10"
11 G10023
G10110 12
12 Hex Head Cap Screw, ¼"-20 x ¾"
Lock Nut, ¼"-20, Grade B
12 GA12215
GA12214
GA12227
GA12226
GA12231
GA12230 1
-
-
-
-
-
Manifold, Center, L .H ., 55⅓", 12 Row 30"
Manifold, Center, R .H ., 55⅓", 12 Row 30"
Manifold, Center, L .H ., 76", 12 Row 36"/38"/40"
Manifold, Center, R .H .,76", 12 Row 36"/38"/40"
Manifold, Center, L .H ., 79", 16 Row 30"
Manifold, Center, R .H ., 79", 16 Row 30"
13 G10830
G10230
G10104 3
3
3 Hex Head Cap Screw, ⅝"-11 x 7½"
Lock Washer, ⅝"
Hex Nut, ⅝"-11
14 GD3180-27
GD3777-10
GD3777-11 2
2
2 Sleeve, ⅞" x 5¾"
Sleeve, 1¾" x 3⅛"
Sleeve, 1¾" x 2½"
15 --- - See “Center Drop Assembly and Driveline” on page P79
16 GD14627 - Coupler, 2"
17 G10676 - Hose Clamp, No . 36
18 GD15792-10
GD15792-09 -
- Hose, 2" x 60", 12 Row 36"/38"/40" And 16 Row 30"
Hose, 2" x 30", 12 Row 36"/38"/40" And 16 Row 30"
19 GD14626 - Elbow, 90°, 2"
20 GA11100 1 Fan Strut
21 G10318
G10230
G10104 1
1
1 Hex Head Cap Screw, ⅝"-11 x 4½"
Lock Washer, ⅝"
Hex Nut, ⅝"-11
22 --- - See “Digital Vacuum Gauge, Analog Vacuum Gauge and Vacuum Fan Assembly” on
page P43
23 G10023 2 Hex Head Cap Screw, ¼"-20 x ¾"
G10110 2 Lock Nut, ¼"-20, Grade B
24 --- - See “Decals, Paint, and Miscellaneous” on page 115
25 GA11114 2 Hose Protector (16 Row 30" Only)
26 G10039
G10228
G10102 Hex Head Cap Screw, ½"-13 x 1¾"
Lock Washer, ½"
Hex Nut, ½"-13
