Center Drop Assembly and Driveline
ITEM
PART NO .
QTY .
DESCRIPTION
1
G10602
3
Spring Pin, ¼" x 1½"
2
GD2548-58
GD2548-60
GD2548-70
GD2548-90
2
-
-
-
Hex Shaft, ⅞" x 58", 12 Row 30" (1 Hole)
Hex Shaft, ⅞" x 60", 12 Row 36"/38" (1 Hole)
Hex Shaft, ⅞" x 70", 12 Row 38"/40" (1 Hole)
Hex Shaft, ⅞" x 90", 16 Row 30" (1 Hole)
3
G10303
G10232
G10106
18
18
18
Carriage Bolt, 5⁄16"-18 x 1"
Lock Washer, 5⁄16"
Hex Nut, 5⁄16"-18
4
G2100-03
8
Bearing, ⅞" Hex Bore, Spherical
5
G3400-01
12
Flangette
6
G10574
G10228
G10102
4
4
4
Carriage Bolt, ½"-13 x 1¼"
Lock Washer, ½"
Hex Nut, ½"-13
7
G10017
G11389
G10228
G10102
4
4
4
4
Hex Head Cap Screw, ½"-13 x 1½"
Flat Washer, ½" SAE
Lock Washer, ½"
Hex Nut, ½"-13
8
G10880
G10110
4
4
Hex Head Cap Screw, ¼"- 20 x 2¼"
Lock Nut, ¼"-20, Grade B
9
GD1114
G10230
G10104
2
4
4
U-Bolt, 7" x 7" x ⅝"-11
Lock Washer, ⅝"
Hex Nut, ⅝"-11
10
GA11075
1
Transfer Case
11
G10001
G10229
G10101
6
6
6
Hex Head Cap Screw, ⅜"-16 x 1"
Lock Washer, ⅜"
Hex Nut, ⅜"-16
12
GD16208
1
Bulkhead Bracket, 12 Row 30"
13
GD16246
1
Bulkhead Bracket, 12 Row 36"/38"/40" And 16 Row 30"
14
G10006
G10230
G10104
2
2
2
Hex Head Cap Screw, ⅝"-11 x 2¼"
Lock Washer, ⅝"
Hex Nut, ⅝"-11
15
GD10348
2
Top Shaft, ⅞" x 7½"
16
G10581
G11389
G10228
G10102
2
12
2
2
Hex Head Cap Screw, ½"-13 x 2¼"
Flat Washer, ½" SAE
Lock Washer, ½"
Hex Nut, ½"-13
17
GA5105
2
Sprocket, 15 Tooth
18
G10233
10
Machine Bushing, 1", 10 Gauge
19
GD10349
1
Bottom Shaft, ⅞" x 9½" (Machines Without Point Row Clutches)
20
GA7154
3
Sprocket W/Bearing, 18 Tooth
21
GA8172
G10536
2
-
Safety Lockup W/Detent Pins, 20"
Detent Pin, ½" x 2½" Grip
22
GD10412
2
Lockup Mount
23
G10305
G10229
G10101
4
4
4
Carriage Bolt, ⅜"-16 x 1"
Lock Washer, ⅜"
Hex Nut, ⅜"-16
24
G3310-74
GR0912
2
-
Chain, No . 40, 74 Pitch Including Connector Link
Connector Link, No . 40
25
GB0287
4
Coupler
26
GD0914-81
GD0914-99
GD0914-111
2
-
-
Hex Shaft, ⅞" x 81", 12 Row 30" (No Holes)
Hex Shaft, ⅞" x 99", 12 Row 36"/38" (No Holes)
Hex Shaft, ⅞" x 111", 12 Row 38"/40" And 16 Row 30" (No Holes)
27
GA7302
2
Spacer
