Kinze 3140 Stack Fold Planter Rev. 5/14 - Manual (Page 117)

Model 3140 M0245-02
Rev . 5/13 P114
TM
Liquid Fertilizer Piston Pump Mount/Drive
ITEM PART NO . QTY .
(Per Assy .)
DESCRIPTION
2 G10602 2 Spring Pin, ¼" x 1½"
3 G10233 5 Machine Bushing, 1", 10 Gauge
4 G3310-80
GR0912 1
-
Chain, No . 40, 80 Pitch Including Connector Link
Connector Link, No . 40
5 GA7180 1 Sprocket, 40 Tooth
6 GD6825-11 .25 1 Hex Shaft, ⅞" x 11¼" (2 Holes)
7 GD5857 1 Spring
8 G10093
G10230
G10104 1
1
1 Hex Head Cap Screw, ⅝"-11 x 8½"
Lock Washer, ⅝"
Hex Nut, ⅝"-11
9 GD10200 2 Sleeve, ¾" Long
10 GA7246 1 Base Mount
11 GA2068 2 Spring W/Plug
12 GA9677
G10640 1
-
Pump Mount W/Grease Fitting
Grease Fitting, ¼"-28
13 GD13656 1 Pump Mount Plate
14 G10871
G10228
G10102 4
4
4 Hex Head Cap Screw, ½"-13 x 6"
Lock Washer, ½"
Hex Nut, ½"-13
15 GD10244-01 1 Sleeve, 71⁄16"
16 G2100-03 2 Bearing, ⅞" Hex Bore, Spherical
17 G10302
G11386
G10232
G10106 6
6
6
6 Carriage Bolt, 5⁄16"-18 x ⅞"
Flat Washer, 5⁄16" SAE
Lock Washer, 5⁄16"
Hex Nut, 5⁄16"-18
18 G10861
G11389
G10102 2
2
2 Hex Head Cap Screw, ½"-13 x 5", Full Thread
Flat Washer, ½" SAE
Hex Nut, ½"-13
19 GA5090
GD5753
GD5752 -
1
1
Tire And Rim Assembly (Specify Brand*)
Tire, 4 .10" x 6" (Specify Brand*)
Inner Tube
20 G10003
G11387
G10101 1
2
2 Hex Head Cap Screw, ⅜"-16 x 1½"
Flat Washer, ⅜" SAE
Hex Nut, ⅜"-16
21 G3400-01 4 Flangette
22 GA9676 1 Flow Divider Mount
23 --- - See “Center Drop Assembly and Driveline” on page P79
24 GA12616 1 Idler Mounting Bracket
25 G10041 2 Hex Head Cap Screw, 5⁄16"-18 x 2"
26 G10019 1 Hex Head Cap Screw, 5⁄16"-18 x 1"
27 GD18065 1 Guide
28 GD2971-17 2 Sleeve, ⅞" Long
29 GA18121 - Flow Divider Mount (EdgeVac Only)
* Specific brand requests will be supplied only as available from current Kinze Repair Parts stock . If a specific brand
requested is not in stock, the brand available will be supplied . Different brand tires may have different diameters .
Change in tire brand may affect rates . Field checks are recommended after any change in contact tires .
