5 Configuration
64 2012-12-31/00561073 [SCR power switch TYA202]
5.1.10 PROFIBUS-DP
Interface parameters for PROFIBUS-DB (see separate manual)
5.1.11 Changing codes
Here, it is possible to assign passwords (4-digit numeric codes) for manual
mode , operator level , and configuration level to protect them from unauthor-
ized access.
Value / settings Description
Device address 1 to 125 If "0" is set as the device address, the bus fault error message
is not displayed.
Data format Motorola, Intel
k / bold = factory setting
Value / settings Description
Code, manual
mode 0000 to 9999 0000 means: no inhibit
9999 means: level is hidden
Code, operator lev-
el 0000 to 9999 0000 means: no inhibit
9999 means: level is hidden
Code, config. level 0000 to 9999 0000 means: no inhibit
k
/ bold = factory setting
