5 Configuration
5.1.3 Analog inputs
The power controller has a voltage and a current input.
These inputs (default setpoint value) specify the output to be provided by the
power controller at the load output.
In most cases, this signal is sent as a standard signal from an electronic con-
troller or PLC and is adjusted with these settings.
1. Analog input inverting:
If, for example, the current measuring range start is set to 20 mA and the current mea-
suring range end is set to 0 mA, the power controller is switched off at 20 mA and
switched on at 0 mA.
Value / settings Description
Current measuring
range 0 to 20 mA This setting specifies which current standard signal is con-
nected.
v Chapter 3.3 "Connection diagram"
4 to 20 mA
Customer-specific
1
Current measuring
range, start 0 to 20 mA Note:
This parameter only appears if "Customer specific" is set for
the current measuring range (see above)!
Current measuring
range, end 0 to 20 mA Note:
This parameter only appears if "Customer specific" is set for
the current measuring range (see above)!
Voltage measuring
range 0 to 10 V This setting specifies which voltage standard signal is con-
nected.
v Chapter 3.3 "Connection diagram"
2 to 10 V
0 to 5 V
1 to 5 V
Customer-specific
1
Voltage measuring
range, start 0 to 10 V Note:
This parameter only appears if "Customer specific" is set for
the voltage measuring range (see above)!
Voltage measuring
range, end 0 to 10 V Note:
This parameter only appears if "Customer specific" is set for
the voltage measuring range (see above)!
k
