1 Introduction
10 2012-12-31/00561073 [SCR power switch TYA202]
1.3 Order details
The nameplate is affixed to the right-hand side of the case.
(1) Basic type
709062 TYA 202 - Three-phase SCR Power Controller in Three-phase Economy Circuit
(2) Version
8 Standard with factory settings
9 Customer-specific programming according to specifications
(3) National language of display texts
01 German (set at factory)
02 English
03 French
(4) Load current 1
020 AC 20 A
032 AC 32 A
050 AC 50 A
100 AC 100 A
150 AC 150 A
200 AC 200 A
250 AC 250 A
(5) Subordinate control loop
100 U, U 2
010 I, I 2 (can be set to U, U 2 )
001 P (can be set to I, I 2 or U, U 2 )
(6) Load voltage 2
024 AC 24 V -20 to +15 %, 45 to 63 Hz
042 AC 42 V -20 to +15 %, 45 to 63 Hz
115 AC 115 V -20 to +15 %, 45 to 63 Hz
230 AC 230 V -20 to +15 %, 45 to 63 Hz
265 AC 265 V -20 to +15 %, 45 to 63 Hz
400 AC 400 V -20 to +15 %, 45 to 63 Hz
460 AC 460 V -20 to +15 %, 45 to 63 Hz
500 AC 500 V -20 to +15 %, 45 to 63 Hz
(7) Interface
00 None
54 RS485/422
64 PROFIBUS-DP
(8) Extra codes
252 Relay (changeover contact) 3 A
257 Optocoupler
(1) (2) (3) (4) (5) (6) (7) (8)
/ - - - - - - Order code
709062 / 8 - 01 - 100 - 100 - 400 - 00 - 252 Order example
1 UL approval in preparation
2 Load voltage = voltage supply for control electronics
Important information:
Subordinate control loop U
2 , code 100: voltage control.
Subordinate control loop I 2 , code 010: enables partial load failure detection, dual energy management, and current limiting.
Subordinate control loop P, code 001: enables partial load failure detection, dual energy management, current limiting, free-running
economy circuit, and R control.
At a load current of 250 A, observe voltage supply for fan!
v Chapter 3.2.5 "Type 709062/X-0X-250-XXX-XXX-XX-25X"
