4 Operation
4.1.5 Display of error messages and special states
Cyclical
display
The symbols for input, subordinate control, and operating mode are displayed
alternately in the info line together with fault messages or information about
particular statuses.
v Chapter 8 "Fault messages and alarms"
Examples
H
All parameters for the maximum device extension level are listed in the fol-
lowing tables. Parameters that are not required are hidden depending on the
order details (see nameplate or device information) or the current configura-
tion.
