2012-12-31/00561073 [SCR power switch TYA202] 11
1 Introduction
1.3.1 Scope of delivery
1.3.2 Accessories
1.3.3 General accessories
Semi-conductor
fuses A semi-conductor fuse is fitted in the power controller to protect the SCR
module. The "LED Fuse" is lit red in the event of a fault.
v Chapter 8.2 "Replacing a defective semi-conductor fuse"
1 operating manual B709062.0
1 SCR power controller in the version ordered
1:1 patch cable
Article Part no.
Setup program 709061 TYA201
(can also be run for TYA202 power controllers) 00544869
USB cable A-connector B-connector 3 m 00506252
Mounting set for DIN rail installation:
Type 709062/X-01-20... 00555172
Type 709062/X-01-32... 00555527
Article Load current
I
nom.
= I
N
Part no.
Super fast semi-conductor fuse 50 A I
N
= 20 A 00513108
Super fast semi-conductor fuse 80 A I
N
= 32 A 00068011
Super fast semi-conductor fuse 80 A I
N
= 50 A 00068011
Super fast semi-conductor fuse 160 A I
N
= 100 A 00081801
Super fast semi-conductor fuse 350 A I
N
= 150 A 00083318
Super fast semi-conductor fuse 550 A I
N
= 200 A 00371964
Super fast semi-conductor fuse 550 A I
N
= 250 A 00371964
