1 Introduction
1.2.2 Note signs
Note:
Reference
Footnote
1.2.3 Performing an action
Action
instruction
Vital text
Command se-
quence
1.2.4 Representation
Keys
H
This symbol is used to indicate particularly important informa-
tion.
v
This symbol refers to further information in other manuals, chap-
ters, or sections.
abc
1 Footnotes are remarks that refer to specific parts of the text. Foot-
notes consist of two parts:
An identification marking in the text, and the footnote text itself.
The identification markings in the text are arranged as sequential
superscript numbers.
h Plug in the
connector
This symbol indicates that an action to be performed is de-
scribed. The individual steps are marked by this asterisk.
This text contains important information, and it is vital that you
read it before proceeding. B
Config. level
r
Controller
r
Operating mode
Small arrows between words are intended to
facilitate faster location of parameters in the
configuration level.
Keys are displayed as symbols or text.
Key combinations are represented by a plus sign.
