2012-12-31/00561073 [SCR power switch TYA202] 63
5 Configuration
5.1.8 Actual value output
The actual value output is an analog output at which different internal values
can be output as a standard signal.
5.1.9 RS422/485
Interface parameters for RS422/485 (see interface description B709061.2)
Value / settings Description
Signal type, actual
value output This setting specifies the standard signal that should be out-
put at the actual value output.
Switched off The actual value output does not issue a signal.
0 to 20 mA The actual value output outputs the "Value to be output" in the
form of a current signal.
4 to 20 mA
0 to 10 V
The actual value output outputs the "Value to be output" in the
form of a voltage signal.
2 to 10 V
0 to 5 V
1 to 5 V
Value to be output This setting specifies the value that should be output at the
actual value output.
Load voltage Example:
The load voltage can vary between 0 and 500 V depending on
the device type.
As the signal range is set ex works to 0 to 9999.9, the end val-
ue must be adjusted to 500.0 to make use of the full signal
range.
These measured values are determined in the master branch.
Exception as of software version 256.01.08:
When the power is selected (in W or kW), the 3-phase current
is output on the actual value output.
Note:
Load voltage
2
= load voltage squared
Load voltage
2
Load current
Load current
2
Power (in W)
Power (in kW)
Resistance
Supply voltage
Device temperature
Setpoint value
Signal range start
value 0 to 9999.9 Lower limit for the "Value to be output"
Signal range end
value 0 to 9999.9 Upper limit for the "Value to be output"
k
/ bold = factory setting
Value / settings Description
Baud rate 9600
19200
38400
Data format 8-1-none Data bits-stop bits-parity check
8-1-odd
8-1-even
8-2-none
Device address 1 to 255
Min. response time 0 to 500 ms
k
/ bold = factory setting
