22 SmartPack User Manual
Record a Preset from a Wall Station
It is possible to record a preset from a wall station if “Remote Record” has been enabled in
the station master. See “Remote Record” on page 15. All SmartPack and SmartSwitch
products on the SmartLink network will record the current output levels for the preset that
is assigned to that button.
Step 1: Set dimmer levels to a desired look via the test menu and/or other DMX control
device.
Step 2: Press and Hold the preset button for 5 seconds.
•
After two seconds, the LED will start to blink at a 1/2 second interval. If the
button is held for 5 seconds a record action will be begin.
• If the button is released before the 5 seconds have elapsed, recording will be
canceled and the normal preset will be activated.
Step 3: Release the preset button. The new recorded preset will activate and the LED
will illuminate.
