2. Install the AirMax5
AirLive AirMax5 User’s Manual 10
2.5 Hardware Installation
Please prepare a screw driver and an outdoor graded PoE Ethernet cable with adequate
length according to your need.
1. Remove the screws from the sides of the
case.
2. Hold the sides of the bottom cases and pull
out in the downward direction.
3. Install the PoE cable to the PoE Port.
Follow the cable guard direction.
4. Slide back the bottom case
The PoE Cable exit
hole should face up
