7. Antenna Alignment
AirLive AirMax5 User’s Manual 100
7.1.2 Mounting Adjustment
The degree you can adjust the AirMax5’s antenna depends on what mounting kit you use:
„
Standard Mounting: The standard strap mount
allows you to rotate the CPE in the horizontal plane
only. As long as 2 wireless devices are at about the
same elevation, this adjustment is already enough.
„ Optional Metal Mounting Kit: The optional metal
mounting kit allow the AirMax5 to rotate in both horizontal (pole mount only) and
vertical direction. It is recommended to use this mounting kit when there is a big
elevation difference between 2 sides of the wireless connection.
