SECTION 6 - JLG CONTROL SYSTEM
3121259 – JLG Lift – 6-25
Table 6-6. Machine Model Adjustment
Adjustment Adjustment Ranges Default Setting
DRIVE Max Speed Accel 25 - 2000mA/sec 275mA/sec
Max Speed Decel 25 - 2000mA/sec 175mA/sec
Max Speed Min 250 - 1800mA 640mA
Max Speed Max 250 - 1800mA 1500mA
Mid-Engine/Max Torque Accel 25 - 2000mA/sec 300mA/sec
Mid-Engine/Max Torque Decel 25 - 2000mA/sec 100mA/sec
Drive to Stop Decel 25-2000mA/sec 1075mA/sec
Drive Mid-Engine/Max Torque Min 250 - 1800mA 640mA
Max Torque Max 250 - 1800mA 1100mA
Mid-Engine Max 250 - 1800mA 1135mA
Max Torque Elevated Max 250 - 850mA 790mA
Mid-Engine Elevated Max 250 - 975mA 900mA
Max Torque Creep 250 - 750mA 725mA
Mid-Engine Creep 250 - 890mA 850mA
STEER Accel 0.0 - 5.0sec 0.8sec
Decel 0.0 - 5.0sec 0.1sec
Min Right 10-100% 35%
Max Right 10-100% 80%
Creep Right 10-100% 50%
Min Left 10-100% 35%
Max Left 10-100% 80%
Creep Left 10-100% 50%
SWING Accel 0.0 - 5.0sec 2.2sec
Decel 0.0 - 5.0sec 1.2sec
Min Left 250 - 1400mA 400mA
Max Left 250 - 1400mA 880mA
Creep Left 250 - 1400mA 600mA
Min Right 250 - 1400mA 400mA
Max Right 250 - 1400mA 880mA
Creep Right 250 - 1400mA 600mA
TOWER LIFT Accel 0.0 - 5.0sec 3.0sec
Decel 0.0 - 5.0sec 1.0sec
Min up 250 - 1400mA 400mA
Max Up 250 - 1400mA 1250mA
Creep Up 250 - 1400mA 600mA
Min Down 250 - 1400mA 400mA
Max Down 250 - 1400mA 750mA
Creep Down 250 - 1400mA 450mA
Soft Down 250 - 1400mA 450mA
