SECTION 3 - CHASSIS & TURNTABLE

3-68

– JLG Lift –

3121259

SEE DETAIL

U

DETAIL

U

FLY VALVE COVER SHOWN TRANSPARENT

CONNECTOR V57 OF
UPPER BOOM HARNESS

CONNECTOR V56 OF
UPPER BOOM HARNESS

CONNECTOR V55 OF
UPPER BOOM HARNESS

Figure 3-46. Cable Installation and Identification - Sheet 8 of 8
