SECTION 6 - JLG CONTROL SYSTEM
3121259 – JLG Lift – 6-17
6.5 CONTROL SYSTEM STARTUP CHECKS
The following actions and checks are performed during sys-
tem startup:
• Inhibit all hydraulic functions
• Energize all Ground and Platform Station indicators and
energize the Platform Alarm.
• Perform assessments as shown in Table 6-5, System Startup
Checks.
Table 6-5. System Startup Checks
Item Checked Function Condition/Action
NOTE: In this table, abbreviations STB=Short To Battery, STG=Short to Ground, and OC=Open Circuit.
System Communications
CAN Bus 1 Ground Module and Platform module to perform suc-
cessful CAN Bus communication Successful communication
Verify healthy CAN Bus and presence of Platform Mod-
ule Successful communication
If applicable, confirm presence of LSS system Successful communication
CAN Bus 2 If applicable, confirm presence of ECU Successful communication
Ground Station
Digital and Functional Switch Inputs Engine Start Open; de-energized
Function Enable Open; de-energized
Swing Left Open; de-energized
Swing Right Open; de-energized
Tower Lift Up Open; de-energized
Tower Lift Down Open; de-energized
Lift Up Open; de-energized
Lift Down Open; de-energized
Telescope In Open; de-energized
Telescope Out Open; de-energized
Jib Up Open; de-energized
Jib Down Open; de-energized
Level Up Open; de-energized
Level Down Open; de-energized
Rotate Left Open; de-energized
Rotate Right Open; de-energized
