SecTiON Vi - RePAiR PARTS (continued)
TABLe 2A
SerIeS 5B BASe PArTS - 5006B thru 5014B
Number in ( ) in Table Relates to Corresponding Number in
in Figure 64
PART
NUMBER
ITEM
PART SIZE
BOILER SIZE
5006B
5007B
5008B
5009B
5010B
5011B
5012B
5013B
5014B
7181301
High Base End Panel
12-1/2 x 25-3/4
(1)
(1)
(1)
(1)
(1)
(1)
(1)
(1)
(1)
7201319
High Base End Panel Insul. - 1” Supertemp
12 x 21-1/2
(2)
(2)
(2)
(2)
(2)
(2)
(2)
(2)
(2)
80861551
Cup Head Pin CL #10 x 1-5/8”
(3)
(3)
(3)
(3)
(3)
(3)
(3)
(3)
(3)
80861503
Speed Clip 1-1/4” x 1-1/8” SS Type 304
(4)
(4)
(4)
(4)
(4)
(4)
(4)
(4)
(4)
61813061
5006B Base Front and Rear Frame Assembly
12-1/2 x 27-3/16
(5)
(5) & (6)
(5)
61813071
5007B Base Front and Rear Frame Assembly
12-1/2 x 32-5/8
(5)
(6)
(5) & (6)
(5)
61813081
5008B Base Front and Rear Frame Assembly
12-1/2 x 38-1/16
(5)
61813091
5009B Base Front and Rear Frame Assembly
12-1/2 x 43-1/2
(5)
61813101
5010B Base Front and Rear Frame Assembly
12-1/2 x 48-15/16
(5)
80861601
Burner Access Panel Attaching Screw
(7)
(7)
(7)
(7)
(7)
(7)
(7)
(7)
(7)
6181301
Base Spacer Assembly
11 x 22-3/4
(8)
(8)
(8)
(8)
71813062
5006B Base Rear Panel
9-5/8 x 26-15/16
(9)
71813072
5007B Base Rear Panel
9-5/8 x 32-3/8
(9)
71813082
5008B Base Rear Panel
9-5/8 x 37-13/16
(9)
71813092
5009B Base Rear Panel
9-5/8 x 43-1/4
(9)
71813102
5010B Base Rear Panel
9-5/8 x 48-11/16
(9)
71813112
5011B Base Rear Panel
9-5/8 x 54-1/8
(9)
71813122
5012B Base Rear Panel
9-5/8 x 59-9/16
(9)
71813132
5013B Base Rear Panel
9-5/8 x 65
(9)
71813142
5014B Base Rear Panel
9-5/8 x 70-7/16
(9)
72013065
Base Rear Panel Insulation - 1” Supertemp
8-3/4 x 26-15/16
(11) 1 pc
72013075
Base Rear Panel Insulation - 1” Supertemp
8-3/4 x 32-3/8
(11) 1 pc
72013085
Base Rear Panel Insulation - 1” Supertemp
8-3/4 x 18-7/8
(11) 2 pcs
72013095
Base Rear Panel Insulation - 1” Supertemp
8-3/4 x 21-5/8
(11) 2 pcs
72013105
Base Rear Panel Insulation - 1” Supertemp
8-3/4 x 24-5/16
(11) 2 pcs
72013115
Base Rear Panel Insulation - 1” Supertemp
8-3/4 x 29-3/4
(11) 2 pcs
72013125
Base Rear Panel Insulation - 1” Supertemp
8-3/4 x 35-3/16
7181312
Front Int. Panel Support Bracket
(13)
(13)
(13)
(13)
7181313
Lower Rear Int. Panel Support Bracket
(14)
(14)
(14)
(14)
7181302
Low Base End Panel
11-7/8 x 25-3/4
(15)
(15)
(15)
(15)
(15)
(15)
(15)
(15)
V
7201320
Low Base End Panel Insul. - 1” Supertemp
11-3/8 x 21-1/2
(16)
(16)
(16)
(16)
(16)
(16)
(16)
(16)
(16)
8221306
5006B Manifold
1-1/2 Pipe x
34-5/16
(17)
8221307
5007B Manifold
(17)
8221308
5008B Manifold
(17)
8221309
5009B Manifold
(17)
8221310
5010B Manifold
(17)
8221311
5011B Manifold
(17)
8221312
5012B Manifold
(17)
8821313
5013B Manifold
(17)
8221314
5014B Manifold
(17)
8231301
Main Burners without Pilot Bracket
(18)
(18)
(18)
(18)
(18)
(18)
(18)
(18)
(18)
8231302
Or Main Burners w/J991 Pilot Bracket (EI Controls)
(19)
(19)
(19)
(19)
(19)
(19)
(19)
(19)
(19)
8231303
Or Main Burners w/Q179 Pilot Bkt (OP/EP Controls)
(20)
(20)
(20)
(20)
(20)
(20)
(20)
(20)
(20)
8231304
Or Main Burners w/Q327 Pilot Bkt (Thermocouple Controls)
(21)
(21)
(21)
(21)
(21)
(21)
(21)
(21)
(21)
822628
Main Gas Orifices (Nat. Gas) - #40 Drill
(22)
(22)
(22)
(22)
(22)
(22)
(22)
(22)
(22)
822629
Or Main Gas Orifices (LP) - #55 Drill
(23)
(23)
(23)
(23)
(23)
(23)
(23)
(23)
(23)
822604
Hitch Pin Clip
(24)
(24)
(24)
(24)
(24)
(24)
(24)
(24)
(24)
61813062
5006B Burner Access Panel Assembly
7-1/4 x 26-15/16
(25)
(25) & (26)
(25)
61813072
5007B Burner Access Panel Assembly
7-1/4 x 32-3/8
(25)
(26)
(25) & (26)
(25)
61813082
5008B Burner Access Panel Assembly
7-1/4 x 37-13/16
(25)
(26)
61813092
5009B Burner Access Panel Assembly
7-1/4 x 43-1/4
(25)
61813102
5010B Burner Access Panel Assembly
7-1/4 x 48-11/16
(25)
7186001
Observation Hole Cover
(12)
(12)
(12)
(12)
(12)
(12)
(12)
(12)
(12)
80860900
1/4 - 20 Wing Nut
(10)
(10)
(10)
(10)
(10)
(10)
(10)
(10)
(10)
8201303
Low Base End to Right Section Fiberglass Rope
3/4 X 25-3/4
