Playback with HOME MEDIA GALLERY inputs 08
73
En
Using the USB interface
It is possible to play back files
1
using the USB interface
on the front of this amplifier.
Confirming the IP Address
After making the network connection, follow the
instructions below to confirm the panel’s IP Address
before accessing the network. (The setup is effective for
Auto only. To perform the procedure, DHCP on your
server or router must be valid.)
1 Press HOME MEDIA GALLERY.
The Home Media Gallery screen is displayed.
2 Select ‘Setup’ ( / then ENTER).
3 Select ‘Network Setup’ ( / then ENTER).
4 Select ‘Automatically acquire IP’ (  then ENTER).
The screen turns from Select mode to Input mode.
5 Select ‘Yes’ ( / then ENTER).
The IP Address is automatically assigned.
The Home Media Gallery supports Auto IP and DHCP
(Dynamic Host Configuration Protocol). If the system
failed to acquire the IP Address or if you want to obtain
different addresses, select
No then enter IP Address and
Subnet mask. Use the 0 to 9 and /// buttons to
enter an address, then press ENTER. You do not need to
enter Default Gateway and DNS Server.
6 Select ‘OK’ (  then ENTER).
The Reset dialog appears on screen.
7 Select ‘OK’ and press ENTER.
The home network module restarts.
A message Setting up Home Media Gallery. Please
wait until initialized. appears on screen.
When the initialization is finished, setting values become
effective and the top menu of the Home Media Gallery
returns.
Note
• For information on DHCP, refer to network device’s
operating instructions.
• You may need to contact your service provider or
network administrator when manually entering an IP
Address.
• Some media servers block or are programmed to
block access to client servers. When connecting this
amplifier, check the media server for client server
access rights.
Connecting a USB device
You can also enjoy content stored on memory cards by
connecting a USB device to this amplifier. When you
insert a USB flash drive or multi-card reader into the USB
port, the root directory or the Device List screen appears.
In addition, you can connect your digital camera directly
to this amplifier using a USB connector cable.
1 Press HOME MEDIA GALLERY.
The Home Media Gallery screen is displayed.
2 Select ‘USB’ ( / then ENTER).
The Device List is displayed on screen with the selected
device highlighted if you have not checked in the
Single
Server/USB box after selecting Setup and then Auto
Connection Setup. If you have checked in the box, the
list is skipped.
3 Select the desired device ( / then ENTER).
You can select a device only when the Device List is
displayed.
4 Press ENTER to navigate to a folder or play a file/
content.
To return to the previous screen, press
RETURN.
Note
• If the Home Media Gallery is launched and the Single
Server/USB box is checked after selecting Setup
and then
Auto Connection Setup, the system
displays the root directory immediately after inserting
a USB device. In this case, you can start from step 4.
When a multi-card reader is inserted, the Device List
appears with the selected device highlighted. In this
case, you can start from step 3.
Note
1 • Compatible USB devices include external magnetic hard drives, portable flash memory (particularly keydrives) and digital audio players (MP3 players)
of format FAT16/32. It is not possible to connect this unit to a personal computer for USB playback.
• Pioneer cannot guarantee compatibility (operation and/or bus power) with all USB mass storage devices and assumes no responsibility for any loss of
data that may occur when connected to this amplifier.
PHONES
SPEAKERS AUTO SURROUND
/STREAM DIRECT
STATUS
LCD
VIEW DIMMER CTRL ZONE2 ZONE3
VIDEO/GAME 2 INPUT
DIGITAL IN S-VIDEO VIDEO L R AUDIO
MULTI-ZONE CONTROL
MCACC
SETUP MIC
USB PARAMETER
SETUP
AUDIO VIDEO
RETURN
ENTER
USB
This amplifier
USB mass
storage device
