Using other functions 11
104
En
Checking the settings of the sound
currently playing, etc.
The audio input/output information, the video input/
output information, the MULTI-ZONE status and this
amplifier’s setting information can be checked by
pressing the status check button on the remote control
unit. The different sets of information are divided
between four screens and displayed on the amplifier’s
LCD. The information shown below can be checked for
the different inputs.
1 Set the operation selector switch to AMP, then
press STATUS to check the system settings.
These appear on the front LCD display. The screen
switches between the five screens below each time the
button is pressed.
• Audio input information
• Audio output information
• Video input/output information
• MULTI-ZONE status
• This amplifier’s settings information
• OFF
2 When you’re finished, press STATUS again to
switch off the display.
Resetting the system
Use this procedure to reset all the amplifier’s settings to
the factory default. Use the front panel controls to do this.
1 Switch the amplifier into standby.
2 While holding down the SETUP button on the front
panel, press  STANDBY/ON.
The display shows RESET NO.
3 Press the ENTER button on the front panel.
4 Select RESET using /, then press the ENTER
button on the front panel.
The display shows
RESET? OK.
5 Press ENTER to confirm.
OK appears in the display to indicate that the amplifier
has been reset to the factory default settings.
• Note that all settings will be saved, even if the
amplifier is unplugged.
SOURCE TV AMP
VOL
VOL CH
SOURCE TV AMP STATUS
THX
CH LEVEL
RETURN
SETUP
STEREO/ AUTO/ STANDARD ADV SURR
STATUS
STATUS AUDIO INPUT
< AUDIO INPUT >
DOLBY DIGITAL
DN31
Emphasis
(( ))
S I G S E L : AU TO [ D I G I TA L ]
44 . 1 kHz
448 kbps
DV D / L D - 5 5 . 0 dB
C
S
SB
LFE
R
SR
SBR
L
SL
SBL
Input seletion
setting and input
singal
Input signal
Input channel
STATUS AUDIO OUTPUT
< AUDIO OUTPUT >
Normal
DV D / L D - 5 5 . 0 dB
L R 1 2 3 4 5 5 4 3 2 1
L R SLA SLB SBL SBR SRB SRA
VSB
C
Output format
Output channel
STATUS VIDEO
< VIDEO INFORMATION >
I N P U T
: 720p / 60Hz
OUTPUT :1080i / 60Hz
ASPECT : 4 : 3
S I G N A L IN :COMPONENT
DV D / L D - 5 5 . 0 dB
Aspect ratio
setting
Input signal
Output signal
Terminal to which
video signal is
being input
STATUS ZONE
< ZONE INFORMATION >
ZONE 2 ON : BD
ZONE 3 OFF : iPod
RECOUT
: – – –
DV D / L D - 5 5 . 0 dB
Zone 2 setting and
input
RECOUT setting
Zone 3 setting and
input
STATUS SYSTEM
< SYSTEM INFORMATION >
MCACC M1 : MEMORY 1
ANALOG ATT : OFF
SLEEP
: 2 8 m i n
SR+ : OFF
DV D / L D - 5 5 . 0 dB
MCACC memory
Sleep timer
Analog ATT
SR+ setting
STATUS OFF
DV D / L D - 5 5 . 0 dB
