Connecting digital audio sources
This amplifier has both digital inputs and outputs, allowing you to connect digital audio components for playback and
for making digital recordings.
Most digital components also have analog connections. See
Connecting analog audio sources on page 26 if you want
to connect these too.
1
Connect an optical-type
1
digital audio output on
your digital component to the OPTICAL IN 6 (CD-R/
TAPE/MD) input.
Use an optical cable for the connection.
2
For recording equipment, connect one of the
optical-type DIGITAL outputs to a digital input on the
recorder.
Use an optical cable to connect to the
SOURCE OUT or
ZONE3/SOURCE OUT.
2
About the WMA9 Pro decoder
This unit has an on-board Windows Media™ Audio 9
Professional
3
(WMA9 Pro) decoder, so it is possible to
playback WMA9 Pro-encoded audio using a coaxial or
optical digital connection when connected to a WMA9
Pro-compatible player. However, the connected PC, DVD
player, set-top box, etc. must be able to output WMA9 Pro
format audio signals through a coaxial or optical digital
output.
