The System Setup menu 06
52
En
Manual speaker setup
This amplifier allows you to make detailed settings to
optimize the surround sound performance. You only need
to make these settings once (unless you change the
placement of your current speaker system or add new
speakers).
These settings are designed to customize your system,
but if you’re satisfied with the settings made in
Automatically setting up for surround sound (MCACC &
Full Band Phase Control) on page 11, it isn’t necessary to
make all of these settings.
Caution
• The test tones used in the System Setup are output at
high volume.
1 Select ‘Manual SP Setup’, then press ENTER.
2 Select the setting you want to adjust.
If you are doing this for the first time, you may want to
adjust these settings in order:
• Speaker Setting – Specify the size and number of
speakers you’ve connected (see below).
• Channel Level – Adjust the overall balance of your
speaker system (page 53).
• Speaker Distance – Specify the distance of your
speakers from the listening position (page 54).
• X-Curve – Adjust the tonal balance of your speaker
system for movie soundtracks (page 54).
• THX Audio Setting – Specify whether you are using
a THX speaker setup (page 54).
3 Make the adjustments necessary for each setting,
pressing RETURN to confirm after each screen.
Speaker Setting
Use this setting to specify your speaker configuration
(size, number of speakers and crossover frequency). It is
a good idea to make sure that the settings made in
Automatically setting up for surround sound (MCACC &
Full Band Phase Control) on page 11 are correct. 1 Note
that this setting applies to all MCACC presets, and
cannot be set independently.
1 Select ‘Speaker Setting’ from the Manual SP Setup
menu.
2 Choose the set of speakers that you want to set,
then select a speaker size.
Use
/ to select the size (and number) of each of the
following speakers: 2
• Front – Select LARGE if your front speakers
reproduce bass frequencies effectively, or if you
didn’t connect a subwoofer. Select
SMALL to send
the bass frequencies to the subwoofer.
• Center – Select LARGE if your center speaker
reproduces bass frequencies effectively, or select
SMALL to send bass frequencies to the other
speakers or subwoofer. If you didn’t connect a center
speaker, choose
NO (the center channel is sent to
the front speakers).
• Surr 3 – Select LARGE if your surround speakers
reproduce bass frequencies effectively. Select
SMALL to send bass frequencies to the other
speakers or subwoofer. If you didn’t connect
surround speakers choose
NO (the sound of the
surround channels is sent to the front speakers or a
subwoofer).
• SB – Select the number of surround back speakers
you have (one, two or none). 4 Select LARGE if your
surround back speakers reproduce bass frequencies
effectively. Select
SMALL to send bass frequencies to
the other speakers or subwoofer. If you didn’t
connect surround back speakers choose
NO.
1 . Au t o M C AC C
2 . O u t p u t S e t u p
3 . M a nu a l M C AC C
4 . F U L L BA N D P H A S E C T R L
5 . D a t a M a n ag e m e n t
6 . M a nu a l S P S e t u p
7 . I n p u t S e t u p
8 . O S D L a n g u ag e
9 . O t h e r S e t u p
: E x i t
S y s t e m S e t u p M E N U
DV D / L D - 5 5 . 0 dB
: R e t u r n
a . S p e a k e r S e t t i n g
b . C h a n n e l L ev e l
c . S p e a k e r D i s t a n c e
d . X - C u r v e
e . T H X Au d i o S e t t i n g
6 . M a nu a l S P S e t u p
DV D / L D - 5 5 . 0 dB
Note
1 If you’re using a THX speaker setup, set all speakers to SMALL.
2 If you select SMALL for the front speakers the subwoofer will automatically be fixed to YES. Also, the center and surround speakers can’t be set to LARGE
if the front speakers are set to SMALL. In this case, all bass frequencies are sent to the subwoofer.
3 Surr A and Surr B can be set when Output Setup is set to Normal.
4 • If you selected All Ch Bi-Amp (in Speaker output setting on page 43) you can’t adjust the surround back settings.
• If the surround speakers are set to NO, the surround back speakers will automatically be set to NO.
• If you select one surround back speaker only, make sure that speaker is hooked up to the left surround back terminal.
: R e t u r n
a . S p e a k e r S e t t i n g
b . C h a n n e l L ev e l
c . S p e a k e r D i s t a n c e
d . X - C u r v e
e . T H X Au d i o S e t t i n g
6 . M a nu a l S P S e t u p
DV D / L D - 5 5 . 0 dB
F ro n t S M A L L
C e n t e r [ S M A L L ]
S u r r A [ S M A L L ]
S u r r B [ S M A L L ]
S B [
S M A L L x2 ]
S W [ Y E S x2 ]
X . OV E R [ 8 0 H z ]
( T H X : A L L S M A L L )
: R e t u r n
6 a . S p e a k e r S e t t i n g
DV D / L D - 5 5 . 0 dB
