Other connections 07
65
En
Basic MULTI-ZONE setup (ZONE 2)
1 Connect a separate amplifier to the AUDIO ZONE2
OUT jacks and a TV monitor to the VIDEO ZONE2 OUT
jacks, both on the rear of this amplifier.
You should have a pair of speakers attached to the sub
zone amplifier as shown in the following illustration.
2 Connect a separate amplifier to the COAXIAL
ZONE2 OUT digital output on the rear of this amplifier.
The amplifier must have an optical digital input to make
this connection. This will allow you to hear the digital
output of a component in a second sub zone.
MULTI-ZONE setup using speaker terminals (ZONE 2)
You must select 7.2ch+ZONE 2 in Speaker output setting
on page 43 to use this setup. Note that the sound in the
sub zone will be temporarily interrupted when controlling
the main zone (for example, changing the input source or
starting playback).
• Connect a TV monitor to the VIDEO ZONE2 OUT
jacks on the rear of this amplifier.
You should have a pair of speakers attached to the R5 and
L5 terminals as shown below.
