The RC Configuration Software
21
# Feature Function
selected, with the labels on the button. Click to Select a button to
configure, modify, read, or delete its macro.
When the button is:
• Blue rimmed, it is assigned a command sequence
• Green, it is selected
• Gray, it is not assigned a macro
Event Macros Tab A series of commands to be executed upon a scheduling time (see
Figure 19 )
7 Button Area
1
Label Text Box Select a button and type the required button label
8 Behavior Drop-
down Box Assign the button response to press and release actions
Button Definition Behavior
Activate on Release
(default) The macro is executed upon releasing
the button
Activate while Pressed The macro is activated and repeated
for as long as the button is pressed
Toggle 1-2-3-4 Cycling macro behavior:
The button can be assigned with up to
4 different macros. Each time it is
pressed, the next macro in the set will
be activated in a cyclic fashion.
2
# Feature Function
9 Write Configuration Button
3
Press to write the configuration of all the buttons to the device
10 Read Configuration Button Press to read the configuration of all the buttons from the PC to the
device
11 Set Device Clock Check Box Check to set the device clock to that of the PC
Button Macro Area
12 Button Macro Display Box Displays the macro RC commands’ Description, Delay and Port in
sequence. Select an RC command to duplicate, delete, or change
its position in the sequence
New Command Button Click to add a new command to the Button Macro display box
4
4.5.2
(see
section )
Duplicate Command Button Duplicate a command in the Button Macro display box
Delete Command Button Delete a command from the Button Macro display box
Button
Move up the selected command
Button
Move down the selected command
13 RC command Area (see section
4.5.3 )
Appears different for different ports and includes the following
features of the command selected in the Button Macro display box:
Description Text Box Optional descriptive text for the command
Port Drop-down Box Displays the port associated with the RC command: Select a port
when modifying or writing a new RC command
14 Delay after command Text Box
5
Set a delay time following the command
6
1 The Button area appears only after selecting a button in the Front Panel tab
2 The number of toggle states can be determined (from 1 to 4). The selected number of toggle states appears above the Button
Macro area (see Figure 18 )
3 This button is enabled only when a device is connected to the PC. Otherwise it is disabled
4 The button macro display box displays under Description and None under Port
5 Shows after checking this option in the configuration menu
6 In seconds or milliseconds, via check box
